Tech specs
Brand
Edge-Core
Product Line
Edge-Core
Model
AS5610-52X
Manufacturer
SMC
Clock Speed
1.2 GHZ
Processor Brand
Broadcom
Processor Number
BCM56846
Processor Type
BCM56846
Flash Memory Installed
2 GB
RAM Installed
2 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qau, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ac, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
9MB packet buffer, Access Control List (ACL) support, ARP support, BOOTP support, Class of Service (CoS), Data Center Bridging Exchange (DCBX) support, DHCP support, DiffServ support, Event log, Flow control, Hot swappable 4 fans, IGMP snooping, LACP support, Layer 2 switching, LLDP support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Quality of Service (QoS), RADIUS support, Rapid Spanning Tree Protocol (RSTP) support, sFlow, Spanning Tree Protocol (STP) support, Trivial File Transfer Protocol (TFTP) support, VLAN support, Weighted Fair Queuing (WFQ), Weighted Random Early Detection (WRED), Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Desktop, Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
128K entries
Manageable
Yes
Ports
48
Product Type
Switch
Remote Management
CLI, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 1, SNMP 2, SNMP 3, SSH-2
Routing Protocol
BGP-4, ECMP, OSPF, OSPFv2, OSPFv3, Static IP routing, VRRP
Subcategory
Network hubs and switches
Switching Type
10 Gigabit Ethernet
Interface Provided
1 x console RJ-45, 1 x management (Gigabit LAN) RJ-45, 1 x USB Type A, 4 x 40Gbit LAN QSFP, 48 x 10GBase-X SFP+
Port Quantity
48
Ports Type (2nd)
QSFP
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Nominal Voltage
AC 120/230 V
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Encryption
MD5
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
5 - 95% (non-condensing)
Airflow Direction
Front to back airflow
Authentication Method
RADIUS, Secure Shell v.2 (SSH2), TACACS+
Capacity
IPv4 routes: 16000, IPv6 routes: 8000, Virtual interfaces (VLANs): 4000
Country
North America
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 960 Mpps, Switching capacity: 640 Gbps
Ports (2nd) Quantity
4
Height
1.7 inch
Height (Rack Units)
1
Weight
18.74 lbs
Width
17.3 inch
Depth
18.6 inch
Color Category
Black
Compliant Standards
CB, cUL, EN 60950, EN55022 Class A, FCC Part 15 A, IEC 60068-2-14, RoHS, UL, VCCI
