Tech specs
Brand
ADTRAN
Product Line
ADTRAN NetVanta
Model
1560-24
Manufacturer
ADTRAN
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3x, UPnP
Features
802.1x authentication, Access Control List (ACL) support, ARP inspection, Authentication, Authorization and Accounting (AAA), Cable Diagnostics Function, DHCP relay, DHCP snooping, DiffServ Code Point (DSCP) support, DoS attack prevention, Dynamic VLAN Support (GVRP), Flow control, Flow mirroring, IGMP proxy, IGMP querier, IGMP snooping, IP source guard, Layer 2 isolation, LLDP support, LLDP-MED, Loop prevention, MAC based VLAN, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Port mirroring, Port Security, Port-based VLAN, Private VLAN, Protocol-based VLANs support, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Schedule PoE, sFlow, Spanning Tree Protocol (STP) support, Strict Priority (SP), VLAN management, VLAN support, VLAN trunking, Voice VLAN, Weighted Random Early Detection (WRED), Weighted Round Robin (WRR)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
10240 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
PoE Budget
370 watt
Ports
24
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, DHCP, HTTP, JSON-RPC, NTP, RMON, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
IGMP, IGMPv2, IGMPv3, MLD, MLDv2
Status Indicators
Link/activity, Status
Subcategory
Network hubs and switches
Switching Type
10 Gigabit Ethernet
Interface Provided
1 x console RJ-45, 1 x management (micro-USB), 2 x 10Gbit LAN SFP+, 24 x 10/100/1000 Base-T RJ-45
Port Quantity
24
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
10 Gigabit SFP+
Frequency
50/60 hertz
Power Consumption Operational
900 watt
Required Voltage
AC 120/230 volt
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-4 degree Fahrenheit
Operating Humidity
0 - 95% (non-condensing)
Authentication Method
RADIUS, Secure Shell (SSH), TACACS+
Capacity
ARP entries: 1000, IPv4 routes (static): 128, IPv6 routes (static): 128, Simultaneous VLANs: 4095
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding bandwidth: 176 Gbps
Ports (2nd) Quantity
4
Height
1.7 inch
Height (Rack Units)
1
Weight
8.6 lbs
Width
17.4 inch
Depth
8.3 inch
Color Category
Black
Compliant Standards
ETSI EN 300 386, FCC Part 15 A, IEC 60950-1, IECS-003 Class A, RCM, UL/CSA60950-1
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Lifetime Limited
