Tech specs
Brand
Arista
Product Line
Arista 7060X5 Series
Manufacturer
Arista Networks
Flash Memory Installed
64 GB
RAM Installed
64 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ba, IEEE 802.3bs, IEEE 802.3cm, IEEE 802.3x
Features
Access Control List (ACL) support, Advanced Event Management suite (AEM), Audio Video Bridging (AVB), Authentication, Authorization and Accounting (AAA), Blue Beacon LED, Class of Service (CoS), CloudVision, Control Plane Protection (CPP), Data Center Bridging Exchange (DCBX) support, DHCP relay, DHCP snooping, DiffServ Code Point (DSCP) support, Enhanced Latency Analyzer and Microburst Detection (LANZ), Enhanced transmission selection (ETS), Equal-Cost Multipath (ECMP), Hot swappable 4 fans, IGMP snooping, Load balancing, Multi Chassis Link Aggregation Group (MLAG), Port mirroring, Priority-Based Flow Control (PFC), Quality of Service (QoS), Rapid PVST+ (RPVST+), sFlow, Software Defined Networking (SDN), Storm Control, Weighted Round Robin (WRR), Zero-touch provisioning (ZTP)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
128K entries
Manageable
Yes
Ports
64
Product Type
Switch
Remote Management
CLI, GPB, IPv4, IPv6, RADIUS, SSH-2, Syslog, TACACS+, Telnet
Routing Protocol
BGP, Bidirectional Forwarding Detection (BFD), ECMP, IGMP, IGMPv2, IGMPv3, IS-IS, MP-BGP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-2, Virtual ARP (VARP), VRF, VRRP, VXLAN
Subcategory
Network hubs and switches
Switching Type
400 Gigabit Ethernet
Interface Provided
1 x 1000Base-T RJ-45 management, 1 x management (RS-232) RJ-45, 1 x USB, 2 x SFP+, 64 x 400Gbit LAN QSFP-DD
Port Quantity
64
Port Type
400 Gigabit QSFP-DD
Ports Type (2nd)
SFP+
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
528 watt
Power Provided
2400 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Required Voltage
AC 200-240 volt
80 PLUS Certification
80 PLUS Platinum
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
5 - 95%
Operating System Required
Arista EOS
Airflow Direction
Back to front airflow
Authentication Method
RADIUS, TACACS+
Capacity
ACL: 2304, Host IPv4 routes: 500000, IGMP groups: 128000, IPv4 groups (Multicast): 256000, IPv4 longest prefix match (LPM) routes: 800000, IPv6 longest prefix match (LPM) routes: 500000, MAC addresses: 128000, Packet buffer size: 114 MB, STP instances: 62, Virtual interfaces (VLANs): 4096
Device Type
Internal power supply
Packaged Quantity
1
Performance
Latency: 825 µs, Throughput: 25.6 Tbps
Ports (2nd) Quantity
2
Height
3.5 inch
Height (Rack Units)
2
Weight
48.39 lbs
Width
17.3 inch
Depth
25.2 inch
Color Category
Gray
Compliant Standards
BSMI, EMC 2014/30/EU, EN 300 386, EN 55032, EN 55035, EN 61000-3-3, EN 62368-1, FCC Class A certified, ICES-003, IEC 60320, IEC 61000-3-2:2019, IEC 62368-1, IEEE 1588, KCC, LVD 2014/35/EU, NRTL, RCM, RFC2460, RFC4443, RFC4861, RFC4862, RoHS 2011/65/EU, RoHS 2015/863/EU, UKCA, VCCI, WEEE 2012/19/EU
Service & Support Details
Limited warranty - parts and labor - 1 year - response time: 10 business days
Limited Warranty
1 Year
