Tech specs
Brand
Aruba
Product Line
HPE Aruba
Model
2930M 40G 8 HPE Smart Rate PoE+ 1-slot Switch
Manufacturer
Aruba
Clock Speed
1.016 GHZ
Processor Brand
ARM
Processor Type
Cortex-A9
Processors Installed
1
Flash Memory Installed
4 GB
Memory Technology
DDR3 SDRAM
RAM Installed
1 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1ad, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3x
Features
Access Control List (ACL) support, ARP support, BOOTP support, Class of Service (CoS), CPU protection, DHCP protection, DHCP server, DHCP support, DiffServ support, Dynamic ARP protection, Dynamic VLAN Support (GVRP), Flow control, Full duplex capability, ICMP Router Discovery Protocol (IRDP), IGMP snooping, Internet Control Message Protocol (ICMP), IPv6 support, Jumbo Frames support, Link Aggregation Control Protocol (LACP), LLDP support, LLDP-MED, MAC address lockout, Management Information Base (MIB), Management Information Base (MIB) II, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), OpenFlow support, Quality of Service (QoS), sFlow, SNTP support, Spanning Tree Protocol (STP) support, STP BPDU Guard, STP Root Guard, Syslog support, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Extensible LAN (VXLAN), VLAN support
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9220 bytes
MAC Address Table Size
32768 entries
Manageable
Yes
PoE Budget
1440 watt
Ports
48
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, HTTP, RMON 1, SNMP, SNMP 1, SNMP 2, SNMP 2c, SNMP 3, SSH, SSH-2, Telnet, XRMON
Routing Protocol
CIDR, ECMP, IGMP, IGMPv2, IGMPv3, MLD, OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2, RIPng, Static IP routing, Static IPv4 routing, Static IPv6 routing
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Expansion Slots
1 (total) / 1 (free) x expansion slot, 1 (total) / 1 (free) x Stacking Module slot
QSFP Slots
1/2.5/5/10GBase-T (PoE+)
Interface Provided
1 x 1000Base-T management, 1 x serial (console), 1 x USB Type B, 36 x 1000Base-T PoE+, 4 x 1000Base-T PoE+, 8 x 1/2.5/5/10GBase-T PoE+
Port Quantity
36
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
Combo 10/100/1000Base-T (PoE+) / 100/1000Base-X SFP
Frequency
50/60 hertz
Power Supplies Supported
2
Encryption
MD5, SSL, TLS
Humidity Range Storage
90% (non-condensing)
Max Operating Temperature
131 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
15 - 95% (non-condensing)
Authentication Method
CHAP, Extensible Authentication Protocol (EAP), PAP, RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
IPv4 routing table entries: 2000, IPv6 routing table entries: 1000, OSPF routes: 200, RIP routes: 10000, Static routes: 256
Device Type
Internal power supply (not installed)
Packaged Quantity
1
Performance
Latency (1 Gbps): 3.1 µs, Latency (10 Gbps): 3.4 µs, Latency (2.5 Gbps): 6.5 µs, Latency (5 Gbps): 4.2 µs, Stacking bandwidth: 100 Gbps, Switching capacity: 320 Gbps, Throughput: 112 Mpps
Ports (2nd) Quantity
4
Ports (3rd) Quantity
8
Height
1.7 inch
Height (Rack Units)
1
Weight
9.81 lbs
Width
17.4 inch
Depth
12.8 inch
Color Category
Black
Compliant Standards
CISPR 22 Class A, CISPR 24, CNS 13438, CSA C22.2 No. 60950-1-07 Second Edition, EN 55022:2010, EN 55024:2010, EN 60825-1:2007, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 61000-3-2, EN 61000-3-3, FCC CFR47 Part 15 A, ICES-003 Class A, IEC 60825-1:2007, IEC 60950-1:2005 + A1:2009 + A2:2013, IEC 61000-3-2, IEC 61000-3-3, IEC 61000-4-11, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, UL 60950-1 Second Edition, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
