Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9124AXD
Manufacturer
Cisco Systems
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11k, IEEE 802.11n (draft 2.0), IEEE 802.11r, IEEE 802.11u, IEEE 802.11v, IEEE 802.15.1, IEEE 802.15.4, IEEE 802.1x, IEEE 802.3, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED 6
Connectivity Technology
Wireless
Data Link Protocols
Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n (draft 2.0)
Features
4K/8K UHD video streaming, 4x4 MU-MIMO technology, 802.1x authentication, Beamforming technology, BSS Coloring, Cisco Trust Anchor module, Cyclic shift diversity (CSD), DFS support, Image signing, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Secure Boot, Target Wait Time (TWT), Wi-Fi Multimedia (WMM) support, Wireless Intrusion Prevention System (WIPS)
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
UPOE
Product Type
Wireless access point
Spread Spectrum Method
OFDMA
Status Indicators
Status
Wireless LAN
802.11a/b/g/n (draft 2.0)/ac/ax, Bluetooth 5.0
Interface Provided
1 x 1/2.5GBase-T - RJ-45, 1 x 1000Base-T - RJ-45, 1 x 1000Base-X - SFP, 1 x management - RJ-45
Software Type
CAPWAP Software Image
Antenna Form Factor
Internal
Directivity
Directional
Encryption
AES, EAP-FAST, EAP-GTC, EAP-SIM, EAP-TLS, EAP-TTLS, PEAP, TKIP, TLS, TTLS, WPA, WPA2, WPA3, WPA3-Enterprise
Internet of Things (IoT) Compatible
Yes
Line Coding Format
OFDMA
Max Operating Temperature
149 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
Operating Humidity
0 - 100%
Authentication Method
EAP-FAST, EAP-TLS, EAP-TTLS, Extensible Authentication Protocol (EAP), MS-CHAP v.2
IoT Communications Technology
Bluetooth Low Energy (LE)
Packaged Quantity
1
Ruggedized Design
Outdoor
Service Activation
No
Height
3.2 inch
Weight
6.39 lbs
Width
10.2 inch
Depth
9.2 inch
Color Category
White
Compliant Standards
47 CFR Part 1.1310, 47 CFR Part 2.1091, ARPANSA, AS/NZS 2772, AS/NZS 4268:2017, AS/NZS 60950-1, AS/NZS 62368.1, AS/NZS CISPR 32 Class B, CAN/CSA C22.2 No. 60950-1, CAN/CSA C22.2 No. 60950-22, CAN/CSA-C22.2 No. 62368-1, CISPR 24:2010, CISPR 32:2015, CNS 13438, EN 300 328 V2.1.1, EN 301 893 V2.1.1, EN 50385:2017, EN 55032:2015/A11:2020, EN 55035:2017, EN 60068-2-5, EN 60950-1, EN 60950-22, EN 61000-3-2:2019, EN 61000-3-3:2013+A1:2019, EN 62368-1, EN55024, ETSI EN 301 489-1 V2.2.3 (2019-11), ETSI EN 301 489-17 V3.1.1 (2017-02), FCC CFR47 Part 15 B, FCC Subpart C 15.247, FCC Subpart C 15.407, ICES-003:2016 issue 6 Class B, IEC 60529, IEC 60950-1, IEC 60950-22, IEC 62368-1, IP66, IP67, Japan Std. 33a, Japan Std. 66, Japan Std. 71, KN 489-1, KN 489-17, KN 61000-3-2, KN 61000-3-3, KN32, KN35:2015, LP0002, MIL-STD-810G 514.4, NEMA 250-2008, QCVN 112:2017, QCVN 118:2018, QCVN 18:2014, RSP-100, RSS-102, RSS-247, RSS-GEN, SRRC, TCVN 7317, UL 60950-1, UL 60950-22, UL 62368-1, VCCI-CISPR 32:2016
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance hardware replacement - lifetime - response time: 10 days
Limited Warranty
Lifetime Limited
