Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9130AXE
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
1 GB
RAM Installed
2 GB
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.15.4, IEEE 802.1ab (LLDP), IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED 6
Connectivity Technology
Wireless
Data Link Protocols
2.5 Gigabit Ethernet, 5 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
4x4 MIMO technology, 802.1x authentication, 8x8 MU-MIMO technology, Cisco Trust Anchor module, Cyclic shift diversity (CSD), Dynamic Frequency Selection (DFS), LLDP support, Maximum Ratio Combining (MRC), MU-MIMO technology, Packet aggregation A-MPDU, Packet aggregation A-MSDU, Secure Boot, Target Wait Time (TWT), Wireless Intrusion Prevention System (WIPS)
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
UPOE
Product Type
Wireless access point
Spread Spectrum Method
OFDMA
Status Indicators
Status
Wireless LAN
802.11a/b/g/n/ac/ax, Bluetooth 5.0
Interface Provided
1 x 1/2.5/5GBase-T (UPOE) - RJ-45, 1 x management - RJ-45, 1 x USB 2.0, Antenna - RF
Software Type
CAPWAP Software Image
Antenna Form Factor
External
Encryption
AES, EAP-FAST, EAP-SIM, PEAP, TLS, TTLS, WPA2, WPA3
Internet of Things (IoT) Compatible
Yes
Line Coding Format
OFDMA
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
-4 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Authentication Method
EAP-FAST, EAP-SIM, Extensible Authentication Protocol (EAP), MS-CHAP v.2
Country
Argentina, Bolivia, Canada, Chile, Colombia, Costa Rica, Dominican Republic, Ecuador, Guatemala, Panama, Paraguay, Peru, Salvador, Uruguay
IoT Communications Technology
Bluetooth Low Energy (LE), Zigbee
Packaged Quantity
1
Ruggedized Design
Indoor
Service Activation
No
Included Accessories
Ceiling grid clip, Low profile bracket
Height
1.6 inch
Weight
3.77 lbs
Width
9.2 inch
Depth
9.2 inch
Color Category
White
Compliant Standards
ARPANSA, AS/NZS 2772, AS/NZS 4268, AS/NZS 60950-1, AS/NZS CISPR 32 Class B, CAN/CSA-C22.2 No. 60950-1, CISPR 24, CISPR 32, CNS, EN 300 328 V2.1.1, EN 301 489-1, EN 301 489-17, EN 301 893 V2.1.1, EN 50385, EN 55032, EN 55035, EN 60601-1-2:2015, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1:2007, EN 62209-1, EN 62209-2, EN55024, FCC CFR47 Part 15 B, FCC CFR47 Part 15 C, FCC Part 15.247, FCC Part 15.407, ICES-003, IEC 60950-1, KN 489-1, KN 489-17, KN 61000-3-2, KN 61000-3-3, KN32, KN35, LP0002, QCVN, RSP-100, RSS-102, RSS-247, RSS-GEN, SRRC, UL 2043, UL 60950-1, VCCI-CISPR 32:2016
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
