Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
4 GB
RAM Installed
4 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
ARP support, Cisco StackWise-160 technology, Class of Service (CoS), Committed Information Rate (CIR), Control plane protection (CoPP), DiffServ Code Point (DSCP) support, Embedded Event Manager (EEM), Energy Efficient Ethernet, First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Management Information Base (MIB), Protocol Independent Multicast (PIM), PVLAN support, PXE support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Spanning Tree Protocol (STP) support, Switched Port Analyzer (SPAN)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
PoE Budget
740 watt
Ports
48
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
CLI, NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
EIGRP, EIGRP for IPv6, HSRP, IS-IS, MSDP, MSTP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP, RIP-1, RIP-2, RIPng, VRRP
Smart
Yes
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interface Provided
1 x console RJ-45, 1 x management (LAN) RJ-45, 1 x network stack device, 40 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W, 8 x 100/1000/2.5G/5G/10GBase-T RJ-45
Port Quantity
40
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
100/1000/2.5G/5G/10GBase-T
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Provided
1000 watt
Power Supplies Supported
2
Redundant Power Supply
Optional
Required Voltage
AC 100-240 volt
Built-in Devices
RFID tag
Encryption
128-bit AES
Humidity Range Storage
5 - 90% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
320,440 Hours
Operating Humidity
5 - 90% (non-condensing)
Capacity
ACL scale entries: 1600, Flexible NetFlow entries: 16000, IPv4 routing table entries: 4000, IPv6 routing table entries: 2000, Packet buffer size: 6 MB, QoS scale entries: 1000, Switched virtual interfaces (SVIs): 1000, VLAN IDs: 4096
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate with stacking: 431 Mpps, Forwarding rate: 297.61 Mpps, Stacking bandwidth: 160 Gbps, Switching bandwidth: 400 Gbps, Switching capacity with stacking: 580 Gbps
Ports (2nd) Quantity
8
Height
1.7 inch
Weight
11.99 lbs
Width
17.5 inch
Depth
15.4 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day, Technical support - phone consulting - 90 days
Limited Warranty
Limited Lifetime
