Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200L
Edition
Network Essentials
Manufacturer
Cisco Systems
Flash Memory Installed
4 GB
RAM Installed
2 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
6MB packet buffer, 802.1x authentication, Cisco StackWise Technology, Class of Service (CoS), Committed Information Rate (CIR), Control plane protection (CoPP), DiffServ Code Point (DSCP) support, Embedded Event Manager (EEM), Energy Efficient Ethernet, First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Management Information Base (MIB), NetFlow, Protocol Independent Multicast (PIM), PVLAN support, PXE support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Switched Port Analyzer (SPAN)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
16000 entries
Ports
48
Product Type
Switch
Remote Management
CLI, NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
EIGRP, EIGRP for IPv6, MSTP, OSPF, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, VRRP
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
1 x console RJ-45, 1 x management (LAN) RJ-45, 1 x network stack device, 4 x 1000Base-X SFP uplink, 48 x 1000Base-T RJ-45
Port Quantity
48
Port Type
10/100/1000
Ports Type (2nd)
Gigabit SFP (uplink)
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Supplies Supported
2
Redundant Power Supply
Optional
Required Voltage
AC 100-240 volt
Humidity Range Storage
5 - 90% (non-condensing)
Max Storage Temperature
158 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
508,700 Hours
Operating Humidity
5 - 90% (non-condensing)
Capacity
ACL scale entries: 1500, FNF entries: 16000, IPv4 routes: 11000, IPv4 routing table entries: 3000, IPv6 routing table entries: 1500, Multicast scale: 1000, QoS hardware queues per port: 8, Switched virtual interfaces (SVIs): 512, Virtual networks: 1, VLANs supported: 1024
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 154.76 Mpps, Stacking bandwidth: 80 Gbps, Switching capacity: 104 Gbps
Ports (2nd) Quantity
4
Height
11.3 inch
Weight
9.59 lbs
Width
17.5 inch
Depth
1.7 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day
Limited Warranty
Limited Lifetime
