Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9300L
Edition
Network Advantage
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
16 GB
RAM Installed
8 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 1588v2, IEEE 802.1ae, IEEE 802.1BA, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z, Wi-Fi CERTIFIED 6
Features
16MB packet buffer, 802.1x authentication, Access Control List (ACL) support, Blue Beacon LED, Cisco StackWise-320 technology, Cisco Trust Anchor module, Cisco Unified Access Data Plane (UADP) 2.0, Class of Service (CoS), Committed Information Rate (CIR), Control plane protection (CoPP), DiffServ Code Point (DSCP) support, Energy Efficient Ethernet, First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Protocol Independent Multicast (PIM), PVLAN support, PXE support, Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Secure Boot, Shaped Round Robin (SRR), Zero-touch provisioning (ZTP)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
PoE Budget
675 watt
Ports
48
Power Over Ethernet (PoE)
UPOE
Product Type
Switch
Remote Management
CLI, gRPC, IPv4, IPv6, NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3, YANG
Routing Protocol
EIGRP, EIGRP for IPv6, MSTP, OSPF, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, VRRP
Stackable
Stackable
Status Indicators
Status
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
1 x console, 1 x management (LAN) RJ-45, 1 x network stack device, 1 x USB 2.0, 12 x 1/2.5/5/10GBase-T RJ-45, 36 x 1000Base-T RJ-45 60 W, 4 x 10GBase-X SFP+ uplink
Port Quantity
48
Port Type
10/100/1000 (UPOE)
Ports Type (2nd)
10 Gigabit SFP+ (uplink)
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Provided
1100 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Encryption
128-bit AES, 256-bit AES
Humidity Range Storage
5 - 90% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
273,820 Hours
Operating Humidity
5 - 90% (non-condensing)
Capacity
ACL scale entries: 5120, IPv4 routes: 32000, IPv6 routes: 16000, Multicast scale: 8000, QoS scale entries: 5120, Switched virtual interfaces (SVIs): 1000, VLANs supported: 4094
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate with stacking: 529.76 Mpps, Forwarding rate: 291.66 Mpps, Switching capacity with stacking: 712 Gbps, Switching capacity: 392 Gbps
Ports (2nd) Quantity
4
Height
19.2 inch
Weight
16.87 lbs
Width
17.5 inch
Depth
1.7 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, FCC CFR47 Part 15 B Class A, ICES-003 Class A, IEC 60950-1, KN32, KN35, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - replacement - lifetime - response time: next business day, Technical support - consulting - 90 days
Limited Warranty
Lifetime Limited
