Tech specs
Brand
Cisco
Product Line
Cisco Industrial Ethernet
Model
1000 Series
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
160 megabyte
RAM Installed
128 megabyte
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
BOOTP support, Bridge protocol data unit (BPDU), Class of Service (CoS), DHCP server, DHCP snooping, DHCP support, DiffServ Code Point (DSCP) support, Full duplex mode, IGMP snooping, Internet Control Message Protocol (ICMP), LLDP support, Management Information Base (MIB), Management Information Base (MIB) II, Multiple Spanning Tree Protocol (MSTP) support, Port Security, Spanning Tree Protocol (STP) support, Static IP mode, Syslog support
Form Factor (Hubs & Switches)
DIN rail mountable
Manageable
Yes
Ports
8
Product Type
Switch
Remote Management
HTTP, RMON, SNMP, SNMP 2, SNMP 3, SSH
Routing Protocol
IGMP, IGMPv2
Subcategory
Network hubs and switches
Switching Type
Fast Ethernet
Interface Provided
8 x 100Base-TX RJ-45
Port Quantity
2
Port Type
10/100 (uplink)
Ports Type (2nd)
10/100 (downlink)
Power Consumption Operational
5.3 watt
Humidity Range Storage
5 - 95% (non-condensing)
Max Operating Temperature
158 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
-4 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
374,052 Hours
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS, Secure Shell (SSH)
Packaged Quantity
1
Ports (2nd) Quantity
6
Height
5 inch
Weight
20.1 ounce
Width
1.8 inch
Depth
4.5 inch
Color Category
Black
Compliant Standards
ANATEL, ANSI/ISA.12.12.01 Class I Division 2 Groups ABCD, AS/NZS CISPR 24, AS/NZS CISPR22:2004 Class A, CB, CEM, China RoHS, CISPR 11 class A, CISPR 22 Class A, EAC, EMC, EMI, EN 50581, EN 55016-1-1 Class A, EN 55016-1-4 Class A, EN 55016-2-3 Class A, EN 61131-2, EN 61326-1, EN55022, FCC CFR47 Part 15 A, ICES-003 Class A, IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-3, IEC 60068-2-30, IEC 60068-2-47, IEC 60068-2-56, IEC 60068-2-6, IEC 60068-2-64, IEC/EN 61000-4-29, IEC/EN 61000-4-3, IEC/EN 61000-4-4, IEC/EN 61000-4-5, IEC/EN 61000-4-6, IEC/EN 61000-4-8, IEC/EN 61000-4-9, IEC/EN 61000-6-1, IEC/EN 61000-6-2, IEC/EN 61000-6-4, IEC/EN/EN61000-4-2, IEC60950-1, IP30, KCC, NAL, NOM, NOM-001-SCFI-1993, RCM, RoHS, UL/CSA/IEC/EN 61010-2-201, UL/CSA60950-1, VCCI Class A, WEEE
