Tech specs
Brand
Datalogic
Product Line
Datalogic PowerScan
Model
PM9501
Edition
Standard Range (SR)
Manufacturer
Datalogic
Wireless Connectivity
RF
Connectivity Technology
Wireless
Barcode Symbology Supported
Australian Post, Aztec code, Base 32, China Han Xin Code, China Post, Codabar, Code 11, Code 128, Code 39, Code 39 CIP, Code 39 Full ASCII, Code 93, Data Matrix, EAN/JAN, EAN-128, EAN-13, EAN-8, GS1 DataBar, GS1 DataBar Composites, GS1 DataBar Expanded Stacked, GS1 DataBar Stacked, GS1 DataBar Stacked Omnidirectional, IATA, Industrial 2 of 5, Interleaved 2 of 5, ISBN, ISBT 128, Japanese Post, Kix (Netherlands) Post, MacroPDF417, MaxiCode, Micro QR code, MicroPDF417, MSI, PDF417, PLANET, Plessey, Portuguese Post, Postnet, QR code, RM4SCC, Royal Mail, Standard 2 of 5, Swedish Post, UPC A Composite, UPC E Composite, UPC-A, UPC-E
Scan Mode
Single-pass
Sensor Resolution
864 x 544
Touchscreen
No
Batteries Installed
1
Battery Chemistry
Lithium ion
Electric Current Required
150 mA (operating)
Power Device Type
Power adapter
Software Type
Datalogic Aladdin, OPOS/JavaPOS Drivers
Drop Specification
6.5 ft to concrete
Form Factor
Portable
Image Sensor Type
Visible laser diode
Interface
RF(910 MHz)
Light Source Wave Length
630-680 nm
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
-4 degree Fahrenheit
Minimum Bar Width
4 milli-inch
Operating Humidity
0 - 95% (non-condensing)
Print Contrast Signal (PCS)
15%
Skew (Degrees)
40
Scanner Functionality
Barcode scanner
Features
Autofocus, Datalogic Motionix technology, Datalogic STAR Cordless System, Datalogic Three Green Lights (3GL), ESD (electrostatic discharge) safe, Triggered
Max Coverage Angle
40
OK Notification
Beeper, LED indicator
Packaged Quantity
1
TTL Decoding
Decoded
Height
8.3 inch
Weight
14.11 ounce
Width
2.9 inch
Depth
4.3 inch
Color
Black, Yellow
Color Category
Black, Yellow
Compliant Standards
CDRH Class II, China RoHS, EU RoHS, IEC 60825 Class 2, IEC 62471, IP65, REACH
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
