Tech specs
Brand
Dell
Product Line
Dell Latitude
Model
5520
Manufacturer
Smart Selection Client Systems
Cores
Quad-Core
Max Turbo Speed
4.2 GHZ
Processor Brand
Intel
Processor Generation
11
Processor Main Features
Intel Turbo Boost Technology 2.0
Processor Number
I5-1135G7
Processor Type
Core i5
Available Memory Slots
1
Cache Memory Installed
8 megabyte
Configuration Features
1 x 8 GB
Data Integrity Check
Non-ECC
Max Memory Supported
64 GB
Memory Card Reader
Card reader
Memory Slots
2
Memory Speed
3200 megahertz
Memory Technology
DDR4 SDRAM
RAM Installed
8 GB
Rated Memory Speed
3200 megahertz
Supported Flash Memory
microSD, microSDHC, microSDXC
Hard Drive Capacity
256 GB
Hard Drive Features
Class 35, NVM Express (NVMe)
Optical Drive Type
No optical drive, None
SSD Form Factor
M.2
Storage Type
SSD
Hard Drive Interface
PCIe 3.0 x4
Bezel Type
Raised
Display Resolution Abbreviation
Full HD
Display Type
LCD
Features
0.17925 mm pixel pitch, Anti-glare
Graphics Controller Model
Intel Iris Xe Graphics
Graphics Processor Series
Intel Iris Xe Graphics
Native Resolution
1920 x 1080
Pixel Density (ppi)
141
Screen Size
15.6 inch
Screen Size (metric)
39.624 centimetre
Touchscreen
No
V-Sync Rate at Max Res.
60 hertz
Widescreen Display
Yes
Frame Rate
30 frames per second
Front Camera Video Resolution
1280 x 720
Image Sensor Type
CMOS
Webcam
Yes
Audio Input Type
Dual array microphone
HDMI Ports
2
Interfaces
2 x HDMI, 2 x USB4 (supports Thunderbolt 4, DisplayPort Alt Mode), Headphone/microphone combo jack, LAN, USB 3.2 Gen 1 (PowerShare)
USB 3.0 Ports
1
USB Type-C Ports
2
USB-C Features
USB Power Delivery
Data Link Protocols
Bluetooth 5.1, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wired Protocol
Gigabit Ethernet
Wireless LAN
802.11a/b/g/n/ac/ax, Bluetooth 5.1
Wireless NIC
Intel Wi-Fi 6 AX 201
Camera Resolution
0.92 Megapixel (standard), 0.23 Megapixel (infrared)
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Form Factor (RAM)
SO-DIMM 260-pin
Input Device Type
Keyboard, Touchpad
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Numeric Pad
Yes
Operating Humidity
10 - 80% (non-condensing)
Shock Acceleration (Non-operating)
160 gram
Shock Acceleration (Operating)
140 gram
Shock Duration (Non-operating)
2 ms half-sine pulse
Shock Duration (Operating)
2 ms half-sine pulse
Vibration Acceleration (Non-operating)
1.3 gram
Vibration Acceleration (Operating)
0.66 gram
Vibration Frequency Range (Non-operating)
RMS (random)
Vibration Frequency Range (Operating)
RMS (random)
Audio Codec
Realtek ALC3204
Features
87 degrees, ExpressCharge, RGB camera
Image Color Disclaimer
The displayed product image may be a different color
Keyboard Backlight
Yes
Output Type
Stereo speakers
Packaged Quantity
1
Platform Supported
Windows
Product Type
Notebook
Security Slot Type
Noble Wedge security slot
Theft Protection
Security lock slot (cable lock sold separately)
Bundled Services
1 Year Hardware Service with Onsite/In-Home Service After Remote Diagnosis - Disti SNS
Operating System
Windows 10 Pro 64-bit Edition
Operating System Edition
Windows 10 Pro
Operating System Platform
Windows 10
Software Type
Dell Applications for Windows 10, Microsoft Office (30 days trial)
Battery Capacity
63 watt hour(s)
Battery Cells
4-cell
Frequency
50/60 hertz
Power Provided
65 watt
Included Accessories
USB-C power adapter
Color Category
Gray
Height
0.9 inch
Weight
3.51 lbs
Width
14.1 inch
Depth
9.3 inch
ENERGY STAR Certified
Yes
EPEAT Compliant
Yes
