Tech specs
Brand
HPE
Product Line
HPE StoreEasy
Model
1670 Expanded Storage
Manufacturer
Hewlett-Packard
Clock Speed
1.8 GHZ
Cores
8-core
Max Turbo Speed
1.9 GHZ
Processor Brand
Intel
Processor Number
3408U
Processor Type
Xeon Bronze
Processors Installed
1
Total Processor Supported
2
Features
HPE SmartMemory, Registered, Single rank
Memory Technology
DDR5 SDRAM
RAM Installed
16 GB
Drive Interface
Serial Attached SCSI 3
Hard Drive Capacity
4 TB
Hard Drive Features
Midline
Port Expansion Hard Drive Type
HDD
Hot-Swap
Hot-swap
Installed Quantity
8
iSCSI support
iSCSI
Max Supported Capacity
320 TB
Network Storage Type
NAS server
Optical Drive Type
None
Rack-mountable
Rack-mountable
RAID Levels
10ADM, 1ADM, RAID 0, RAID 1, RAID 10, RAID 5, RAID 50, RAID 6, RAID 60
Spindle Speed (rpm)
7200 revolutions per minute
Storage Controller Name
HPE MR416i-o Gen11 SPDM
Total Storage Capacity
32 TB
Type
RAID
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Trusted Platform Module (TPM)
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
DHCP, DNS, FTP, FTPS, HTTP, HTTPS, Microsoft CIFS, Network File System (NFS), Server Message Block (SMB), Web-based Distributed Authoring and Versioning (WebDAV)
Expansion Bays
12 (total) / 4 (free) x hot-swap - 3.5" LFF
Expansion Slots
1 (total) / 1 (free) x PCI Express 4.0 x16 (half-length, full-height), 1 (total) / 1 (free) x PCI Express 4.0 x8 (half-length, full-height), 1 (total) / 1 (free) x PCI Express x8 (power only) (half-length, full-height), 2 (total) / 0 (free) x FlexibleLOM
Interface Provided
1 x HPE iLO (service) - Type A, 4 x Ethernet 1000Base-T (rear)
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Provided
800 watt
Power Supplies Installed
1
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
Required Voltage
AC 200-240 volt
80 PLUS Certification
80 PLUS Platinum
Software Type
HPE iLO Advanced Premium Security Edition with 1 Year Support, HPE StoreEasy Management Console
Storage Operating System
Microsoft Windows Storage Server IoT 2022 Standard
Hard Drive Form Factor
3.5" LFF
Hard Drive Form Factor (metric)
8.9 cm LFF
Storage Controller Interface
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
50 degree Fahrenheit
Operating Humidity
8 - 90% RH (non-condensing)
Operation Type
Internal power supply
Supported Devices
12
Controllers Included
1
Installed Devices/Modules
8
Packaged Quantity
1
Cables
2 x power cable (C13-C14) - 6 ft
Included Accessories
6 x hot-plug high-performance redundant fan
Height
3.4 inch
Height (Rack Units)
2
Weight
106.59 lbs
Width
17.6 inch
Depth
33 inch
Color Category
Black, Red, Silver
Compliant Standards
WEEE 2002/95/EC
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - parts and labor - 3 years - on-site - response time: next business day
Limited Warranty
3 Year
