Tech specs
Brand
Perle
Product Line
Perle IOLAN
Model
SDG1 RJ45
Manufacturer
Perle Systems
Clock Speed
600 megahertz
Processor Brand
ARM
Processors Installed
1
Flash Memory Installed
4 GB
RAM Installed
512 GB
Communication Mode
Full-duplex, Half-duplex
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet, RS-232, RS-422, RS-485
Data Transfer Rate
230 Kbps
Features
1.5 KV Magnetic Isolation, 15 KV Electrostatic Discharge Protection, Flow control, IPv6 support, Metal housing, RAW TCP, TruePort, TrueSerial technology, Wall mountable
Form Factor
External
Product Type
Device server
Status Indicators
Link/activity, Power, Receive, Transmit
Interface Provided
1 x 1000Base-T - RJ-45, 1 x serial
Power Consumption Operational
1.9 watt
Max Operating Temperature
131 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
238,681 Hours
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
Kerberos, LDAP, RADIUS, Secure Shell (SSH), TACACS+
Country
United States
Device Type
External power adapter
Packaged Quantity
1
Height
0.9 inch
Weight
8.11 ounce
Width
2.5 inch
Depth
3.5 inch
Color Category
Black
Compliant Standards
CAN/CSA-C22.2 No. 62368-1, CISPR 24:2010, CISPR 32:2015 Class A, Directive 2011/65/EU, EN 55024:2010, EN 55032:2015 Class A, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 61000-4-11, EN 61000-4-2:2009, EN 61000-4-3:2006, EN 61000-4-4:2004, EN 61000-4-5:2006, EN 61000-4-6:2009, EN 61000-4-8, EN 62368-1:2014, FCC Class B certified, ICES-003:2016, IEC 62368-1, IP40, REACH, RoHS, UL 62368-1, WEEE
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
