Tech specs
Brand
Raritan
Product Line
Raritan Dominion PX
Model
PX3-5405V
Manufacturer
Raritan
Remote Management
HTTP, HTTPS, SNMP 2, SNMP 3, SSH, Telnet
Remote Management Interface
Ethernet 10/100, RS-232
Input Connectors
1
Interface Provided
1 x LAN - RJ-45, 1 x monitoring - RJ-12, 1 x monitoring - RJ-45, 1 x RS-232 - 9 pin D-Sub (DB-9), 1 x USB - 4 pin USB Type B, 2 x USB - 4 pin USB Type A
Emergency Power Off
Active power meter, Cascadable, Current meter, LED display, Power factor meter, Real power meter, Splash-proof plug, Voltage monitoring
Frequency
50/60 hertz
Input Connector Type
Power NEMA 5-20P
Input Voltage Range
AC 100 - 120 V
Max Input Current
16 ampere
Output Connector Quantity
20
Power Capacity
1900 volt ampere per kilogram
Power Output Connectors Details
20 x power NEMA 5-20R 16 A
Provided Voltage
AC 120 volt
Required Voltage
AC 120 volt
Form Factor (Power Device)
Rack-mountable
Max Operating Temperature
140 degree Fahrenheit
Min Operating Temperature
41 degree Fahrenheit
Operating Humidity
5 - 85%
Packaged Quantity
1
Product Type
Power distribution unit
Subcategory
Power distribution devices
Cables
Power cable 10 ft
Height
51.1 inch
Height (Rack Units)
0
Width
2 inch
Depth
2.6 inch
Color
Black powder coat
Color Category
Black
Compliant Standards
cULus, FCC Part 15 A, ICES-003 Class A, RoHS, UL
ENERGY STAR Certified
No
