Tech specs
Brand
Ruckus
Product Line
Ruckus ICX
Model
7250-24
Manufacturer
Ruckus Wireless
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
802.1x authentication, Access Control List (ACL) support, Auto-uplink (auto MDI/MDI-X), BOOTP support, DHCP relay, DHCP server, DHCP snooping, DiffServ Code Point (DSCP) support, DiffServ support, DoS attack prevention, Dynamic ARP Inspection (DAI), Energy Efficient Ethernet, Flow control, GARP VLAN Registration Protocol (GVRP), High Availability, IGMP proxy, IGMP snooping, IPv4 support, IPv6 support, LACP support, Link Fault Signaling (LFS), MAC address filtering, Management Information Base (MIB), Metro Ring Protocol (MRP) support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, OpenFlow support, Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), Port mirroring, Port Security, Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Fault Notification (RFN), sFlow, Spanning Tree Protocol (STP) support, STP Root Guard, Strict Priority (SP), Syslog support, Tagged VLAN, Trunking, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Switch Redundancy Protocol (VSRP) support, VLAN Stacking, VLAN support, Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
16000 entries
Manageable
Yes
Max Units In A Stack
12
Ports
24
Product Type
Switch
Remote Management
CLI, HTTPS, RMON, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP
Routing Protocol
ECMP, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, Static IPv4 routing, Static IPv6 routing, VRRP
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
QSFP Slots
10 Gigabit SFP+
Interface Provided
1 x 1000Base-T RJ-45 management, 1 x mini-USB Type B management, 1 x USB Type A, 2 x 10Gbit LAN SFP+ uplink/stacking, 24 x 1000Base-T RJ-45, 6 x Gigabit LAN SFP+ upgradable to 10G
Port Quantity
24
Port Type
10/100/1000
Ports Type (2nd)
1 Gigabit Ethernet SFP+
Features
Redundant Power System (RPS) connector
Frequency
50/60 hertz
Power Consumption Operational
57.6 watt
Power Provided
135 watt
Redundant Power Supply
Optional
Encryption
AES
Humidity Range Storage
0 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-13 degree Fahrenheit
MTBF
676,362 Hours
Operating Humidity
5 - 95% (non-condensing)
Operating System Required
HP-UX, IBM AIX, Microsoft Windows, SunSoft Solaris
Airflow Direction
Front and side to back
Authentication Method
Extensible Authentication Protocol (EAP), RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
QoS hardware queues: 8, Spanning Tree Protocol instances: 254, Virtual interfaces (VLANs): 4095
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 154 Mpps, Latency: 1.5 µs, Stacking bandwidth: 80 Gbps, Switching capacity: 208 Gbps
Ports (2nd) Quantity
6
Ports (3rd) Quantity
2
Height
1.7 inch
Height (Rack Units)
1
Weight
8.29 lbs
Width
17.3 inch
Depth
11 inch
Compliant Standards
CAN/CSA C22.2 No. 60950-1-07, CISPR 22 Class A, EN 60825-1, EN 60825-2, EN 60950-1 Second Edition, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-3, EN50082-1, EN55022 Class A, EN55024, FCC Part 15 A, ICES-003, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, RoHS 6/6, UL 60950-1 Second Edition, VCCI Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime, Technical support - 3 years
Limited Warranty
Lifetime Limited
