Tech specs
Brand
Ruckus
Product Line
Ruckus ICX
Model
7550-48F-E2
Manufacturer
Ruckus Wireless
Flash Memory Installed
4 GB
RAM Installed
4 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1ae, IEEE 802.1AX, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
3 fans, 802.1x authentication, Access Control List (ACL) support, Authentication, Authorization and Accounting (AAA), Auto-uplink (auto MDI/MDI-X), BOOTP support, BPDU Guard, Change of Authorization (CoA), Class of Service (CoS), Denial of Service (DoS), DHCP server, DHCP snooping, Digital Optical Monitoring (DOM) support, Dynamic VLAN Support (GVRP), Encapsulated Remote SPAN (ERSPAN), Flexible authentication, Flow control, Full duplex capability, IGMP snooping, Inter-Packet Gap (IPG) adjustment, Link Fault Signaling (LFS), MAC address authentication, MAC address filtering, MAC based VLAN, MAC Learning Disable, MACsec support, Metro Ring Protocol (MRP) support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, Multiple VLAN Registration Protocol (MVRP), Neighbor Discovery Protocol (NDP), Network Timing Protocol (NTP), OpenFlow support, Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), PIM-SM snooping, Port Loop Detection, Port mirroring, Precision Time Protocol (PTP), Private VLAN, Protected ports, Q-in-Q tunneling, Quality of Service (QoS), Remote Fault Notification (RFN), Remote Switch Port Analyzer (RSPAN), Root Guard, Secure Copy (SCP), sFlow, SmartZone, Strict Priority (SP), Syslog support, Telnet client, Telnet server, Uni-Directional Link Detection (UDLD), Virtual Cable Test (VCT) technology, Virtual Extensible LAN (VXLAN), Virtual Switch Redundancy Protocol (VSRP) support, Voice VLAN, Web authentication, Weighted Round Robin (WRR)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
12288 bytes
Manageable
Yes
Max Units In A Stack
12
Ports
48
Product Type
Switch
Remote Management
CLI, HTTP, HTTPS, SNMP 1, SNMP 2c, SNMP 3, SSH-2, TFTP
Routing Protocol
ECMP, RIP-1, RIP-2, Static IPv4 routing, Static IPv6 routing
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
10 Gigabit Ethernet
Expansion Slots
1 (total) / 1 (free) x expansion slot
QSFP Slots
40/100 Gigabit QSFP+
Interface Provided
1 x 1000Base-T RJ-45 management, 1 x console (USB) Type C, 1 x console RJ-45, 12 x 1/10GBase-X SFP+, 2 x 100Gbit/40Gbit LAN QSFP+ uplink/stacking, 36 x 100 / 1000Base-X SFP
Port Quantity
36
Port Type
Gigabit SFP
Ports Type (2nd)
1 Gigabit / 10 Gigabit SFP+
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
166.8 watt
Power Provided
400 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Redundant Power Supply Supported
1+1
Encryption
AES
Humidity Range Storage
5 - 95% (non-condensing)
Max Operating Temperature
113 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
532,359 Hours
Operating Humidity
10 - 90% (non-condensing)
Airflow Direction
Front to back airflow
Authentication Method
RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
Maximum ports per trunk: 32, Multicast groups: 8192, Priority QoS queues: 48, PVLANs supported: 256, Spanning Tree Protocol instances: 512, Trunk groups: 256, Virtual interfaces (VLANs): 4095, VRF instances: 128
Device Type
Internal power supply
Packaged Quantity
1
Performance
Aggregate stacking bandwidth: 2.4 Tbps, Forwarding capacity: 678 Mpps, Switching capacity: 912 Gbps
Ports (2nd) Quantity
12
Ports (3rd) Quantity
2
Height
1.7 inch
Height (Rack Units)
1
Weight
14.15 lbs
Width
17.3 inch
Depth
16 inch
Color Category
Black
Compliant Standards
AS/NZS 55022, CAN/CSA C22.2 No. 60950-1-07, EN 55022/CISPR 22 Class A, EN 60825-1, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-3, EN55024, FCC Part 15 A, ICES-003, IEC 60950-1, IEC 68-2-27, IEC 68-2-32, IEC 68-2-36, IEC 68-2-6, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Lifetime Limited
