Tech specs
Brand
Sophos
Product Line
Sophos SG
Model
230
Manufacturer
Sophos Appliances
RAM Installed
8 GB
Hard Drive Capacity
120 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
1
Connectivity Technology
Wired
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Firewall protection, Intrusion Prevention System (IPS), Modular design, VPN passthrough
Form Factor
External
Ports
6
Product Type
Security appliance
Expansion Slots
1 (total) / 1 (free) x expansion slot
Interface Provided
1 x RS-232 - RJ-45, 1 x USB 2.0 - Type A, 1 x VGA, 2 x USB 3.0 - Type A, 6 x 1000Base-T - RJ-45
Bundled Services
1 year TotalProtect
Frequency
48 - 62 hertz
Nominal Voltage
AC 120/230 V
Power Consumption Operational
78 watt
Built-in Devices
Status LCD
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Concurrent connections: 2500000, Maximum number of users: unlimited
Country
United States
Device Type
Internal power supply
Packaged Quantity
1
Network Device
Antivirus throughput: 800 Mbps, Connection rate: 22000 connections per second, Firewall throughput: 13 Gbps, Intrusion prevention throughput: 3 Gbps, VPN throughput: 2 Gbps
Height
1.7 inch
Height (Rack Units)
1
Weight
11.24 lbs
Width
17.2 inch
Depth
11.5 inch
Compliant Standards
CB, C-Tick, FCC Class A certified, UL, VCCI
Service & Support Details
New releases update - 1 year, Technical support - 1 year
