Tech specs
Brand
Sophos
Product Line
Sophos XGS
Model
7500
Manufacturer
Sophos
Drive Interface
NVM Express
Hard Drive Capacity
960 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
2
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, 40 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Deep Packet Inspection (DPI), Firewall protection, Firmware upgradable, HeartBeat Technology, Intrusion Prevention System (IPS), SD-WAN support, Two bypass interface pairs, VPN support, Web threat protection, Zero-Touch Deployment
Form Factor
Rack-mountable
Ports
22
Product Type
Security appliance
Expansion Slots
4 (total) / 4 (free) x expansion slot
Interface Provided
1 x management - RJ-45, 1 x micro-USB, 1 x serial - RJ-45, 12 x 10Gb Ethernet - SFP+, 2 x 40Gb Ethernet - QSFP28, 2 x USB 3.0 - Type A, 8 x 1000Base-T - RJ-45
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
306 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Required Voltage
AC 100-240 volt
Built-in Devices
Status LCD
Encryption
TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Capacity
Concurrent connections: 48000000, Concurrent IPSec VPN tunnels: 12500, Concurrent SSL VPN tunnels: 19000, New connections per second: 1100000, Xstream SSL/TLS concurrent connections: 1280000
Country
United States
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Firewall latency (64-byte UDP): 5.4 µs, Firewall throughput (IMIX): 70.5 Gbps, Firewall throughput: 160 Gbps, IPS throughput: 71.5 Gbps, NGFW throughput: 58 Gbps, Threat protection throughput: 26 Gbps, VPN throughput (IPSec): 117 Gbps, Xstream SSL/TLS inspection: 19.5 Gbps
Cables
1 x micro-USB cable
Included Accessories
Sliding rack rails
Height
3.5 inch
Height (Rack Units)
2
Weight
39.68 lbs
Width
17.2 inch
Depth
25.4 inch
Color Category
White
Compliant Standards
ANATEL, BSMI, CB, CCC, FCC, ISED, KC, NOM, RCM, SDPPI, UKCA, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1 Year
