Tech specs
Brand
Synology
Product Line
Synology Disk Station
Model
DS923+
Manufacturer
Synology
Clock Speed
2.6 GHZ
Cores
Dual-Core
Max Turbo Speed
3.1 GHZ
Processor Brand
AMD
Processor Number
R1600
Processor Type
Ryzen Embedded
Processors Installed
1
Total Processor Supported
1
Features
ECC
Max Memory Supported
32 GB
Memory Technology
DDR4 SDRAM
RAM Installed
4 GB
iSCSI support
iSCSI
Network Storage Type
NAS server
Optical Drive Type
None
RAID Levels
JBOD, RAID 0, RAID 1, RAID 10, RAID 5, RAID 6
Total Storage Capacity
0 GB
Type
RAID
Compliant Standards
DLNA CERTIFIED
Data Link Protocols
Ethernet, Fast Ethernet, Gigabit Ethernet
Features
Advanced snapshot technology, Alibaba Cloud OSS support, Apple Time Machine compatible, Backblaze B2 support, Baidu cloud support, B-tree file system (Btrfs), DLNA Media Server, DNS server, Dropbox support, EXT4 file system, Failover protection, File and folder-level data restoration, File self-healing, Firewall protection, Flexible storage quota system, Google Cloud Platform support, Google Drive support, Hardware encryption, High Availability, hubiC support, Inline compression, Let's Encrypt, Link Aggregation, MailPlus server, MegaDisk support, Microsoft OneDrive support, Mobile users support, NFS Kerberos authentication, OpenStack compatible, OpenStack Swift-compatible, RADIUS Server, RAID migration, Rsync compatible, Shared folder encryption, SMB encryption, SSD read-write cache, SSD trim, Storage Pool, Surveillance station, Synology Hybrid RAID, Tencent COS support, VPN Server, Wake On LAN (WOL), Wake on WAN (WOW), WebDAV server support, Windows ACL, Yandex Disk support
Host Connectivity (compact list)
Gigabit Ethernet
Network Services Compatibility
Apple File Protocol (AFP), Calendaring Extensions to WebDAV (CalDAV), FTP, Microsoft Active Directory (AD), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), Server Message Block (SMB), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Web-based Distributed Authoring and Versioning (WebDAV)
Network Standard
DNS, IPSec, iSCSI, L2TP, OpenVPN, PPTP, SFTP, TCP/IP
Remote Management
HTTP, HTTPS, LDAP, RADIUS, SNMP, SSH, Telnet
Expansion Bays
4 (total) / 4 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x2, 2 (total) / 1 (free) x SO-DIMM 260-pin, 2 (total) / 2 (free) x M.2 2280
Interface Provided
1 x eSATA, 2 x Ethernet 1000Base-T - RJ-45, 2 x USB 3.2 Gen 1 - Type A
Frequency
50/60 hertz
Power Provided
100 watt
Required Voltage
AC 100-240 volt
Software Type
McAfee AntiVirus (Trial)
Encryption
AES-NI, SSL, TLS
Storage Controller Interface
Serial ATA-600 / eSATA
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
8 - 80% RH
Operation Type
External power adapter
Sound Emission
22.9 dBA
Supported Devices
4
Compression Format
H.264, H.265
Features
Built-in 2 cooling fans, Citrix Ready, Power recovery, Reset button, Scheduled power on/off, Security lock slot (cable lock sold separately)
Image Resolution
1280x720, 1920x1080, 2048x1536, 2591x1944, 3840x2160
Installed Devices/Modules
0
IP Cameras Supported
40
Packaged Quantity
1
Security Slot Type
Kensington security slot
Cables
2 x network cable
Included Accessories
Accessory pack
Height
6.5 inch
Weight
4.94 lbs
Width
7.8 inch
Depth
8.8 inch
Color Category
Black
Compliant Standards
BSMI, CCC, EAC, FCC, KC, RCM, RoHS, UKCA, VCCI
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
