Tech specs
Brand
TSC
Product Line
TSC
Model
MH241T
Manufacturer
TSC Taiwan Semiconductor Co
Flash Memory Cards Supported
microSD
Flash Memory Installed
512 megabyte
Memory Card Reader
Card reader
Memory Technology
SDRAM
RAM Installed
256 megabyte
Product Type
Print server
Interface
LAN, Serial, USB 2.0, USB host
Interface Required Connections
1 x LAN - RJ-45, 1 x RS-232, 1 x USB 2.0 - 4 pin USB Type B, 2 x USB host - 4 pin USB Type A
Fonts
CG Triumvirate Bold Condensed
Max B/W Print Resolution
203 dpi
Max Mono Print Speed
840.9 Inches per minute
Max Print Length
1000 inch
Max Print Size
Roll (4.5 in)
Max Roll Diameter
8 inch
Max V-Document Size
450 in
Maximum Print Width
4.09 inch
Media Thickness Range
0.0024 in - 0.01 in
Min V-Document Size
0.2 in
Print Output Type
Monochrome
Print Speed
Up to 840.9 inch/min - max speed
Wireless Print Technology
Wired
Barcode Symbology Supported
Aztec code, China Post, Codabar, Code 11, Code 128A, Code 128B, Code 128C, Code 39, Code 93, Data Matrix, EAN-128, EAN-13, EAN-8, GS1 DataBar, Interleaved 2 of 5, MaxiCode, MSI, PDF417, Plessey, Postnet, QR code, RSS, UPC-2, UPC-5, UPC-A, UPC-E
Media Feeders
1 x manual - Roll (4.5 in)
Media Size Class
Other
Media Sizes
Roll (0.79 in - 4.49 in)
Media Type
Other
Touchscreen
No
Frequency
50/60 hertz
Power Device Type
Power supply
Power Device Form Factor
Internal
Display Graphic Resolution
480 x 272
Language Emulation
DPL, EPL, TSPL-EZD, ZPL, ZPL II
Max Operating Temperature
104 degree Fahrenheit
Media Type
Black mark labels, Continuous labels, Die cut labels, Fanfold labels
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
25 - 85% (non-condensing)
Roll Core Diameter
1.5 in, 3 in
Built-in Devices
4.3 inch LCD touch screen
Country
United States
Label Printer Features
Open head sensor, Paper near end sensor, Realtime clock, Reflective/black mark sensor, Ribbon encode sensor, Ribbon end sensor, Transmissive/gap sensor
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Direct Thermal, Thermal Transfer
Text Styles
Rotated text
Cables
1 x USB cable
Fonts Included
1 x scalable, 8 x bitmapped
Height
12.8 inch
Weight
34.61 lbs
Width
10.9 inch
Depth
19.8 inch
Color Category
Black
Compliant Standards
BIS, BSMI, CCC, CoC, cUL, EAC, FCC Class A certified, KC, RCM Class A, RoHS, S Mark, TUV, UL, WEEE
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 2 years, Limited warranty - platen - 1 year / 50 km, Limited warranty - printhead - 1 year / 25 km
Limited Warranty
2 Year
