Tech specs
Brand
VMware
Product Line
VMware SD-WAN Edge
Model
610-LTE
Manufacturer
Vmware
Flash Memory Installed
16 GB
RAM Installed
4 GB
Cellular Data Connectivity Technology
LTE
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1ad, IEEE 802.1Q, IEEE 802.1x
Connectivity Technology
Wired, Wireless
Data Link Protocols
Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
2T2R MIMO technology, 3G/4G USB Dongle Support, DHCP client, DHCP relay, DHCP server, Fanless, High Availability, Layer 7 load balancing, Link Aggregation, MAC address filtering, Multiple SSID support, NAT support, NetFlow, Port forwarding, Quality of Service (QoS), RADIUS support, Routing, Syslog support, VLAN Tagging, Wall mountable
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Product Type
Application accelerator
Remote Management
SNMP
Routing Protocol
BGP, OSPF, Static IP routing
Wireless LAN
802.11a/b/g/n/ac
Expansion Slots
2 (total) / 2 (free) x SIM card
Interface Provided
1 x console - mini-USB, 2 x 1000Base-X - SFP (mini-GBIC) (WAN / LAN), 2 x USB 3.0, 6 x 1000Base-T - RJ-45 (WAN / LAN)
Frequency
50/60 hertz
Power Consumption Operational
16 watt
Required Voltage
AC 100-240 volt
Antenna Form Factor
Internal
Antennas
2
Encryption
128-bit AES, 256-bit AES, IKEv2, PKI, SHA-1, SHA-2, TLS 1.2
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 85%
Capacity
Flows per second: 2400, Maximum concurrent flows: 240000, Maximum number of routes: 100000, Maximum segments: 16, Maximum simultaneous SSIDs: 4, Tunnel scale: 50
Country
Americas
Device Type
External power adapter
Packaged Quantity
1
Pricing Units
1 edge
Network Device
Internet traffic (IMIX): 200 Mbps, Maximum throughput (1300-byte packet size): 350 Mbps, Maximum throughput (IMIX) across EHA Link: 200 Mbps, Throughput (64-byte packet size): 40 Mbps
Height
2 inch
Weight
2.91 lbs
Width
8.1 inch
Depth
7.9 inch
Color Category
White
Service & Support Details
Extended service agreement - replacement - 1 year
Limited Warranty
1-year warranty
