Tech specs
Brand
WD
Product Line
WD Blue SN580
Model
WDS100T3B0E
Manufacturer
Western Digital Arkeia
Endurance Type
600 TB
Form Factor (Short)
M.2
Form Factor (Short) (metric)
M.2
Hard Drive Capacity
1 TB
Hard Drive Features
ATA security, nCache 4.0 technology, TCG Pyrite 2.01
Hard Drive Type
Internal hard drive
HD Interface
PCI Express 4.0 x4 (NVMe)
Max Internal Data Transfer Rate
4150 MBps
Max Write Transfer Rate
4150 MBps
Storage Interface
PCI Express 4.0 x4 (NVMe)
4KB Random Read
600000 IOPS
4KB Random Write
750000 IOPS
Interface Provided
1 x PCI Express 4.0 x4 (NVMe) - M.2 M key
Power Consumption
3.3 mW (sleep), 65 mW (active)
Compatible Bay
M.2 2280
Hard Drive Form Factor
M.2 2280
Hard Drive Form Factor (metric)
M.2 2280
Max Operating Temperature
185 degree Fahrenheit
Max Storage Temperature
185 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
1,500,000 Hours
Shock Acceleration (Operating)
1500 gram
Shock Duration (Operating)
0.5 ms half-sine
Vibration Acceleration (Non-operating)
4.9 gram
Vibration Acceleration (Operating)
5 gram
Vibration Frequency Range (Non-operating)
7-800 Hz
Vibration Frequency Range (Operating)
10-2000 Hz
Packaged Quantity
1
Product Type
Solid State Drive
Height
0.1 inch
Weight
0.19 ounce
Width
0.9 inch
Depth
3.1 inch
Compliant Standards
BSMI, CAN ICES-3(B)/NMB3(B), FCC, KCC, Morocco, RCM, TUV, UL, VCCI
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
