Tech specs
Brand
Yealink
Product Line
Yealink MVC Series
Model
MCoreKit-C4-MS
Manufacturer
Yealink
Connectivity Technology
Wired, Wireless
Data Link Protocols
Bluetooth 5.2, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
Trusted Platform Module 2.0 (TPM 2.0)
Product Type
Network adapter
Connectivity Technology
Wired, Wireless
Interface Provided
1 x network - Ethernet 10Base-T/100Base-TX/1000Base-T - RJ-45, 1 x Yealink Mtouch port - RJ-45, 3 x audio / video - HDMI - 19 pin HDMI Type A, 4 x SuperSpeed USB 3.0 - 9 pin USB Type A
Display Screen Technology
IPS
Features
10-point multi-touch
Maximum External Resolution
5K
Native Resolution
1280 x 800
Screen Size
8 inch
Screen Size (metric)
20.3 centimetre
Touchscreen
No
Power Device Type
Power adapter
Software Type
Windows 10 IoT Enterprise 64-bit
Built-in Devices
Motion sensor
Conferencing System Type
Video conferencing kit
Power Device Form Factor
External
Input Device Type
8" touchscreen
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 95%
Packaged Quantity
1
System Kit Content
MCore Pro Mini-PC, MTouch E2 touch panel
Cables
3 x HDMI cable
Included Accessories
Mounting bracket
Dimensions Details
Mini-PC - Width 6.6 in Depth 7.8 in Height 1.5 in Weight 24.3 oz, Touch console - Width 8 in Depth 5.9 in Height 3.9 in Weight 2.2 lbs
Color Category
Black
Compliant Standards
CCC, FCC, IC, RCM, REACH, RoHS, UKCA, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 2 years
Limited Warranty
2 Year
