Tech specs
Brand
Zebra
Product Line
Zebra ZD200 Series
Model
ZD220
Manufacturer
Zebra Technologies
Flash Memory Installed
256 megabyte
Memory Technology
SDRAM
RAM Installed
128 megabyte
Product Type
None
Interface
USB 2.0
Interface Required Connections
1 x USB 2.0
Max B/W Print Resolution
203 dpi
Max H-Document Size
4.4 in
Max Mono Print Speed
240.9 Inches per minute
Max Print Length
39 inch
Max Print Size
Roll (4.4 in)
Max Roll Diameter
5 inch
Maximum Print Width
4.09 inch
Media Thickness Range
0.003 in - 0.01 in
Min H-Document Size
1 in
Print Output Type
Monochrome
Print Speed
Up to 240.9 inch/min - max speed
Wireless Print Technology
Wired
Barcode Symbology Supported
Aztec code, Codabar, CODABLOCK, Code 11, Code 128, Code 39, Code 49, Code 93, Data Matrix, EAN-13, EAN-8, Industrial 2 of 5, Interleaved 2 of 5, ISBT 128, LOGMARS, MaxiCode, MicroPDF417, MSI, PDF417, PLANET, Plessey, Postnet, QR code, Standard 2 of 5, UPC, UPC-A, UPC-E
Media Feeders
1 x manual - 1 roll - Roll (4.4 in)
Media Size Class
Other
Media Sizes
Roll (1 in - 4.4 in)
Media Type
Other
Frequency
50/60 hertz
Power Device Type
Power supply
Power Factor Correction (PFC)
Yes
Language Emulation
EPL2, Extensible Mark-up Language (XML), EZPL, ZPL II
Max Operating Temperature
105.8 degree Fahrenheit
Media Type
Continuous labels, Die cut labels, Fanfold labels, Receipt paper, Tag stock, Wristband labels
Min Operating Temperature
39.9 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Roll Core Diameter
0.5 in, 1 in, 1.5 in, 2 in, 3 in
Built-in Devices
Peeler
Country
United States
Label Printer Features
Black Mark sensor, Gap sensor, Peeler
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Direct Thermal
Fonts Included
16 x bitmapped ZPL II, 2 x scalable ZPL, 5 x expandable EPL2
Height
5.9 inch
Weight
2.43 lbs
Width
6.9 inch
Depth
8.7 inch
Color Category
Black
Compliant Standards
BIS, BSMI, CCC, C-Tick, cTUVus, CU, EN 300 328, EN 301 893, EN 61000-3-2, EN 61000-3-3, EN 62311, EN55022 Class B, EN55024, FCC Class B certified, FCC Part 15.209, FCC Part 15.247, ICES-003, IEC 60950-1, INMETRO, KCC, NOM, RSS-247, S Mark, SABS, VCCI
Energy Star
Yes
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
