Tech specs
Brand
ZyXEL
Product Line
Zyxel XGS2220 Series
Model
XGS2220-54HP
Manufacturer
Zyxel USA
Flash Memory Installed
64 megabyte
RAM Installed
1 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.3at, IEEE 802.3bt
Features
2KV Surge protection, 6KV ESD Protector (contact discharge), 8KV ESD Protector (air-gap discharge), Anti-ARP spoofing, ARP inspection, DHCP relay, DHCP server, DHCP snooping, Dynamic VLAN Support (GVRP), Guest VLAN, IGMP filtering, IGMP snooping, IGMP throttling, Layer 3 switching, Port isolation, Smart Fan, Static route, VLAN ID filtering, VLAN management, VLAN trunking
Form Factor (Hubs & Switches)
Desktop, Rack-mountable
Jumbo Frame Support
9000 bytes
MAC Address Table Size
32K entries
Manageable
Yes
PoE Budget
600 watt
Ports
54
Power Over Ethernet (PoE)
PoE++
Product Type
Switch
Routing Protocol
IGMP
Subcategory
Network hubs and switches
Switching Type
10 Gigabit Ethernet
QSFP Slots
100/1000/2.5G/5G/10G (uplink)
Interface Provided
2 x 10Gbit LAN RJ-45 PoE++, 4 x 10Gbit LAN SFP+ uplink, 40 x Gigabit LAN RJ-45 PoE+, 8 x Gigabit LAN RJ-45 PoE++ - 60 W
Port Quantity
40
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
10/100/1000 (PoE++)
Frequency
50/60 hertz
Required Voltage
AC 100-240 volt
Humidity Range Storage
10 - 90% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
-4 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
214,388 Hours
Operating Humidity
10 - 95% (non-condensing)
Capacity
IP interfaces: 32, IPv4 forwarding table entries: up to 1000, IPv6 forwarding table entries: up to 512, Routing tables: 64
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 161 Mbps, Packet buffer size: 2 MB, Switching capacity: 216 Gbps
Ports (2nd) Quantity
8
Ports (3rd) Quantity
2
Ports (4th) Quantity
4
Ports (4th) Type
10 Gigabit SFP+ (uplink)
Rack Mounting Kit
Included
Included Accessories
Power cord
Height
1.7 inch
Weight
11.02 lbs
Width
17.4 inch
Depth
13 inch
Color Category
Black
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
