Tech specs
Brand
Axis
Product Line
AXIS P37 Series
Model
P3737-PLE
Manufacturer
Axis Communications
Flash Memory Installed
8 GB
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
4 GB
Network Interface
Ethernet 10Base-T/100Base-TX/1000Base-T
Protocols
ARP, Bonjour, CDP, CIFS, DDNS, DHCPv4, DHCPv6, DNS, DNSv6, FTP, HTTP, HTTP/2, HTTPS, ICMP, ICMPv4, ICMPv6, IGMP, IGMPv2, IGMPv3, IPv4, IPv6, LLDP, MQTT, NTP, NTS, QOS, RTCP, RTP, RTSP, RTSPS, SFTP, SMB, SMTP, SNMP 1, SNMP 2c, SNMP 3, SRTP, SSH, Syslog, TCP, TLS, UDP, UPnP, USGv6, Zeroconf
Connectivity Technology
Wired
Ports
LAN - RJ-45
Image Sensor Size
4 x 1/2.7"
Image Sensor Type
PS RGB CMOS
Tilt
25 to 95
Audio Support
Yes
Audio Support Features
Speaker pairing, Two-way audio via optional audio and I/O interface
Camera Mechanical Design
Multi-sensor
Digital Video Capture Resolution
2560 x 1440, 2592 x 1944, 320 x 180, 320 x 240
Max Frame Rate
30 frames per second
Max Video Resolution
2592 x 1944
Motion Detection
Yes
Panning Range (degree)
-90 to +90
Shutter Speed (Max)
1/50000 second (time unit)
Shutter Speed (Min)
1/5 second (time unit)
Video Capture
2560 x 1440 @ 25/30 fps, 2592 x 1944 @ 20 fps
Camera Type
Network panoramic camera
Night Vision
Yes
Low Voltage Power
PoE Plus Class 4
Power Consumption Operational
13.25 watt
Software Type
AXIS Object Analytics, AXIS Video Motion Detection
Angular Field of View (D, Max, Degree)
134
Angular Field of View (D, Min, Degree)
47
Angular Field of View (H, Max, Degree)
99
Angular Field of View (H, Min, Degree)
37
Angular Field of View (V, Max, Degree)
70
Angular Field of View (V, Min, Degree)
28
Camera Iris
Fixed iris
Encryption
TLS 1.2, TLS 1.3
Focal Length Control
Vari-focal
Form Factor
Dome
Indoor/Outdoor
Outdoor
Infrared Distance
49 ft
Infrared LEDs
Yes
Lens Aperture
F/1.9-3.2
Max Focal Length
8.1 millimetre
Max Operating Temperature
122 degree Fahrenheit
Min Focal Length
3.2 millimetre
Min Focus Distance
1.6 ft
Min Operating Temperature
-22 degree Fahrenheit
Minimum Illumination
0 lux - B&W - F1.9 - 50 IRE, 0 lux - IR, 0.19 lux - color - F1.9 - 50 IRE
Operating Humidity
10 - 100% RH (condensing)
Optical Zoom
2.5
Protection
Tamper-resistant / weatherproof
Sensor Size (metric)
4 x 9.4 mm (1/2.7")
Total Pixels
4 x 5,000,000 pixels
Video Formats
AVC, H.264B, H.264H, H.264M, H.265, HEVC, MJPEG, MPEG-4 Part 10, MPEG-H Part 2
Video Input
Color
Country
Argentina, Australia, Brazil, China, Europe, Japan, Korea, United Kingdom, United States
Features
2D Noise Reduction Technology, 3D Noise Reduction Technology, Adaptive Bitrate (ABR), Axis device ID, Axis Edge Vault, Barrel distortion correction, Brute force delay protection, Day/night threshold, Deep learning processing unit (DLPU), Digest authentication, Dynamic text, Forensic WDR, Image overlay, Infrared-cut filter, IP address filtering, IR Corrected lens, Lightfinder technology, Low latency mode, Multi-Bitrate (MBR), ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, OptimizedIR, Password protection, Pixel Counter Support, Polygon privacy mask, Privacy Mask Function, Remote focus, Remote zoom, Scene metadata, Secure Boot, Secure keystore, Signed firmware, Signed video, Text overlay, Tone mapping, Variable Bit Rate (VBR), Video streaming indicator, Zipstream technology
Packaged Quantity
1
Included Accessories
Cable gaskets, Connector guard
Height
3.6 inch
Weight
4.41 lbs
Width
10 inch
Depth
10 inch
Color
NCS S 1002-B, White
Color Category
White
Compliant Standards
AS/NZS 62368.1:2022, AS/NZS CISPR 32 Class A, BFR-free, CAN/CSA C22.2 No. 62368-1 Third Edition, CFR free, CISPR 32 Class A, CISPR 35, cUL, EAC, EN 50121-4, EN 55032 Class A, EN 55035, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 63000:2018, ETSI EN 303 645, FCC Part 15 B Class A, FIPS 140, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC/EN 60529 IP66, IEC/EN 60529 IP67, IEC/EN 62262 IK09, IEC/EN 62471, IEC/EN/UL 62368-1 Third Edition, IEEE 802.1ar, IEEE 802.1x, IEEE 802.3at, IS 13252, ISO 21207 method B, KC, KS C 9832 Class A, KS C 9835, MIL-STD-810H, NEMA 250 Type 4X, NEMA TS-2 (2.2.7-2.2.9), NIST SP500-267, PVC-free, RCM, REACH 2006/1907, RoHS 2011/65/EU, UKCA, UL, VCCI Class A, VDMA 24364
TAA Compliant
Yes
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
