Tech specs
Brand
Comtrol
Product Line
Comtrol DeviceMaster
Model
RTS
Manufacturer
Comtrol
Flash Memory Installed
8 megabyte
Flash Memory Size
8 megabyte
Memory Technology
SDRAM
RAM Installed
32 megabyte
Optical Drive Type
None
Connectivity Technology
Wired
Data Link Protocols
RS-232, RS-422, RS-485
Data Transfer Rate
230.4 Kbps
Features
ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), BOOTP support, DHCP support, DIN rail mountable, RARP support
Form Factor
External
Network Standard
ICMP/IP, TCP/IP, UDP/IP
Ports
8
Product Type
Device server
Remote Management
HTTP, HTTPS, SNMP, Telnet, TFTP
Status Indicators
Link/activity, Receive, Status, Transmit
Interface Provided
2 x 100Base-TX - RJ-45, 8 x RS-232/422/485 - RJ-45
Frequency
50/60 hertz
Nominal Voltage
AC 120/230 V
Power Consumption Operational
3.6 watt
Encryption
SSL, TLS 1.2
Max Operating Temperature
167 degree Fahrenheit
Min Operating Temperature
-40 degree Fahrenheit
MTBF
30.9 years
Operating Humidity
50 - 95% (non-condensing)
Authentication Method
Secure Shell (SSH)
Device Type
External power adapter
Packaged Quantity
1
Height
1.8 inch
Weight
3.59 lbs
Width
10.8 inch
Depth
6.3 inch
Color
Black
Compliant Standards
AS/NZS CISPR 22, cULus, EMC, EN 60950, EN 61000-4-11, EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN55022, EN55024, FCC Part 15 B Class A, ICES-003, IEC 60950, RoHS, UL 60950
Service & Support Details
Limited warranty - 5 years
Integrated System
5-year warranty
