Tech specs
Brand
Ruckus
Product Line
Ruckus ICX
Model
7150-48
Manufacturer
Ruckus Wireless
Flash Memory Installed
2 GB
RAM Installed
1 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1BR, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
802.1x authentication, Access Control List (ACL) support, Class of Service (CoS), DHCP relay, DHCP server, DHCP snooping, DiffServ Code Point (DSCP) support, DiffServ support, DoS attack prevention, Dynamic ARP Inspection (DAI), Fanless, Flow control, IPv4 support, IPv6 support, Network Timing Protocol (NTP), OpenFlow support, Quality of Service (QoS), sFlow, Strict Priority (SP), Tagged VLAN, Trusted Platform Module (TPM), Type of Service (ToS), Virtual Cable Test (VCT) technology, Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
16384 entries
Manageable
Yes
Max Units In A Stack
8
Ports
48
Product Type
Switch
Remote Management
CLI, HTTP, HTTPS, SCP, SNMP 3, Telnet, TFTP
Routing Protocol
ECMP, OSPF, OSPFv2, OSPFv3, PIM-SM, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, Static IPv4 routing, Static IPv6 routing, VRRP, VRRPE, VRRPv3
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
QSFP Slots
Gigabit SFP
Interface Provided
1 x console RJ-45, 1 x management RJ-45, 1 x USB-C management, 2 x 1000Base-T RJ-45 uplink, 4 x Gigabit LAN SFP+ upgradable to 10G, 48 x 1000Base-T RJ-45
Port Quantity
48
Port Type
10/100/1000
Ports Type (2nd)
10/100/1000 (uplink)
Frequency
50/60 hertz
Power Provided
65 watt
Power Supplies Installed
1
Power Supplies Supported
1
Encryption
AES
Humidity Range Storage
0 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-13 degree Fahrenheit
Operating Humidity
5 - 95% (non-condensing)
Authentication Method
RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
ARP entries: 2048, QoS hardware queues: 8, Spanning Tree Protocol instances: 254, Virtual interfaces (VLANs): 4095
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 134 Mpps, Stacking bandwidth: 320 Gbps, Switching capacity: 180 Gbps
Ports (2nd) Quantity
2
Ports (3rd) Quantity
4
Height
1.7 inch
Height (Rack Units)
1
Width
17.3 inch
Depth
14.6 inch
Color Category
Black
Compliant Standards
AS/NZS 55022, CISPR 22 Class A, CSA C22.2 No. 60950-1-07, EN 60825-2, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-6-3, EN50081-1, EN55022, FCC Class A certified, ICES-003, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-36, IEC 60068-2-6, IEC 60950-1 Second Edition, RoHS 6/6, UL 60950-1 Second Edition, VCCI Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Lifetime Limited
