Tech specs
Manufacturer
Ruckus Wireless
Brand
Ruckus
Product Line
Ruckus ZoneFlex
Model
T301s
Country Kits
United States
Packaged Quantity
1
Antenna Form Factor
Internal
Directivity
Directional
Antenna Qty
2
Ruggedized Design
Outdoor
Capacity
Concurrent stations: 500, Simultaneous VoIP clients: 30
Type
Wireless access point
Form Factor
External
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Wireless Protocol
802.11a/b/g/n/ac
Data Transfer Rate
867 MBps
Wi-Fi Bands
2.4 GHz, 5 GHz
Power Over Ethernet (PoE)
PoE
Status Indicators
Power, Status
Features
BeamFlex+ Smart Antenna Technology, Captive Portal, Dual-stream (2x2), Jumbo Frames support, Load balancing, Network Admissions Control (NAC), Pole mountable, Quality of Service (QoS), Wall mountable, Wi-Fi Multimedia (WMM) support
Compliant Standards
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, Wi-Fi CERTIFIED
VoIP
Yes
Interfaces
1 x 1000Base-T (PoE) - RJ-45
Included Accessories
Mounting brackets
Encryption Algorithm
AES, WPA, WPA2, WPA2-Enterprise, WPA-Enterprise, WPA-PSK
Authentication Method
Active Directory, Basic Service Set Identifier (BSSID), RADIUS
Compliant Standards
CAN/CSA-C22.2 No. 60950-1, CB, CISPR 22, CISPR 24, EN 50121-1, EN 50121-4, EN 50385, EN 60950-22, EN 61000-4-2, EN 61000-4-3, EN 61000-4-5, EN 62311, EN50155, EN60950-1:2006 + A12:2011, ETSI 300 019, FCC, GR-1089-CORE, ICNIRP, IEC 60529 IP67, IEC 60950-1:2005 Second Edition, IEC 60950-22, IP67, RoHS, WEEE
Width
9.4 inch
Depth
7.7 inch
Height
4.3 inch
Weight
5.51 lbs
Type
1-year warranty
Service & Support
Limited warranty - 1 year
Min Operating Temperature
-4 degree Fahrenheit
Max Operating Temperature
131 degree Fahrenheit
