Tech specs
Brand
Afinia
Product Line
Afinia
Model
L801
Manufacturer
Afinia
Product Type
Print server
Interface
LAN, USB 2.0
Interface Required Connections
1 x LAN, 1 x USB 2.0
Color
5-ink
First Print Out Time B/W
10 second (time unit)
Ink Cartridge Configuration
5 cartridges (1 each: cyan, magenta, yellow; 2 black)
Inkjet Technology
Memjet Waterfall Printhead Technology
Max B/W Print Resolution
1600 dpi
Max H-Document Size
8.5 in
Max Mono Print Speed
720 Inches per minute
Max Print Size
Roll (8.5 in)
Max Roll Diameter
8 inch
Max V-Document Size
39.37 in
Maximum Print Width
8.5 inch
Media Capacity
1 roll
Media Thickness Range
0.0051 in - 0.0118 in
Min H-Document Size
2 in
Nozzle Configuration
70440 nozzles
Print Output Type
Color
Print Speed
Up to 360 inch/min - 1600x1600 dpi, Up to 720 inch/min - 1600x1200 dpi
Barcode Symbology Supported
Code 39, PDF417
Media Size Class
Other
Media Sizes
Roll (2 in), Roll (8.5 in)
Media Type
Other
Frequency
50/60 hertz
Power Device Type
Power supply
Software Type
BarTender Basic Edition, Drivers & Utilities
Auto Cutter
Yes
Auto Paper Cutter
Yes
Max Operating Temperature
95 degree Fahrenheit
Media Type
Glossy labels, Labels, Matte labels, Polyester labels, Polypropylene labels, Semi-gloss labels, Vinyl labels
Min Operating Temperature
59 degree Fahrenheit
Operating Humidity
20 - 80% (non-condensing)
Operating System Required
Microsoft Windows 7 (32/64 bits), Microsoft Windows Vista (32/64 bits), Microsoft Windows XP 32-bit
Roll Core Diameter
3 in
Built-in Devices
Status LCD
Office Machine Type
Printer
Printer Product Type
Label printer
Scanner Functionality
None
Features
Firmware upgradable
Printer Functions
Printer
Packaged Quantity
1
Print Technology
Ink-jet
Height
19.1 inch
Weight
82.89 lbs
Width
18.9 inch
Depth
21.1 inch
Color Category
Black, Gray
ENERGY STAR Certified
No
EPEAT Compliant
No
Service & Support Details
Limited warranty - 1 year
Limited Warranty
1-year warranty with product registration
