Tech specs
Brand
APC
Product Line
APC Smart-UPS VT
Model
40kVA with 4 Battery Modules
Manufacturer
APC
Remote Management
HTTP, SNMP
Expansion Slots
1 (total) / 0 (free) x SmartSlot
Input Connectors
1
Interface Provided
1 x management, 1 x management (RS-232) - 9 pin D-Sub (DB-9)
Batteries Quantity
4
Battery Technology
Lead acid
Frequency
47 - 70 hertz
Frequency Provided
47 - 53 hertz
Input Connector Type
Hardwire
Input Voltage Range
AC 304 - 477 V
Load Type
At full load
Max Run Time
6.9 min at full load
Output Connector Type
Hardwire, Terminal block (screw)
Power Capacity
40000 volt ampere per kilogram
Power Output Connectors Details
1 x hardwire, 1 x terminal block (screw)
Provided Voltage
AC 400 volt
Required Voltage
AC 400 volt
Supported Batteries Quantity
4
UPS Technology
On-line
Waveform Type
Sinewave
Battery Run Time (Up To)
6.9 minute (time unit)
Software Type
Drivers & Utilities
Form Factor (Power Device)
External
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
0 - 95%
Features
Audible alarm, Emergency power off, LED display
Packaged Quantity
1
Product Type
UPS
Subcategory
UPS
Included Accessories
Bolt down brackets
Height
59.1 inch
Weight
1386.69 lbs
Width
22 inch
Depth
31.9 inch
Color
Black
Compliant Standards
EN 50091-2, IEC 61000-3-2, IEC 61000-3-3, IEC 62040-3, ISO 14001, ISO 9001
Service & Support Details
Limited warranty - 1 year
Integrated System
1-year warranty
