Tech specs
Brand
Axis
Product Line
AXIS
Model
P3265-LVE-3
Manufacturer
Axis Communications
Flash Memory Installed
8 GB
Memory Cards Supported
microSD Card, microSDHC Card, microSDXC Card
RAM Installed
1 GB
Network Interface
Ethernet 10Base-T/100Base-TX
Protocols
Bonjour, CDP, CIFS, DDNS, DHCP, DNS, FTP, HTTP, HTTPS, ICMP, IGMP, IPv4, IPv6, LLDP, MDNS, MQTT, NTP, NTS, QOS, RTCP, RTP, RTSP, RTSPS, SFTP, SIP, SMB, SMTP, SNMP, SRTP, SSH, Syslog, TCP/IP, TLS, UDP/IP, UPnP, USGv6, Zeroconf
Connectivity Technology
Wired
Ports
LAN/power - RJ-45
Image Sensor Size
1/2.8"
Image Sensor Type
PS RGB CMOS
Tilt
75
Audio Formats
AAC-LC, ADPCM, G.711, G.726, LPCM, OPUS
Audio Support
Yes
Audio Support Features
Two-way audio capability
Camera Mechanical Design
Fixed
Max Frame Rate
60 frames per second
Max Video Resolution
1920 x 1080
Motion Detection
Yes
Panning Range (degree)
-180 to +180
Shutter Speed (Max)
1/66500 second (time unit)
Shutter Speed (Min)
2 second (time unit)
Camera Type
Network surveillance camera
Night Vision
Yes
Low Voltage Power
PoE Class 3
Power Consumption Operational
4.8 watt
Software Type
Windows decoder 1-user license
Angular Field of View (H, Max, Degree)
100
Angular Field of View (H, Min, Degree)
36
Angular Field of View (V, Max, Degree)
53
Angular Field of View (V, Min, Degree)
20
Auto Iris Control
P-Iris
Encryption
EAP-TLS, MSCHAPv2, PEAP, TLS 1.2, TLS 1.3
Focal Length Control
Vari-focal
Form Factor
Dome
Indoor/Outdoor
Outdoor
Infrared Distance
131 ft
Infrared LEDs
Yes
Lens Aperture
F/1.8
Max Focal Length
8.9 millimetre
Max Operating Temperature
122 degree Fahrenheit
Min Focal Length
3.4 millimetre
Min Focus Distance
19.7 inch
Min Operating Temperature
-40 degree Fahrenheit
Minimum Illumination
0 lux - IR, 0.02 lux - B&W - F1.8 - 50 IRE, 0.1 lux - color - F1.8 - 50 IRE
Operating Humidity
10 - 100% RH (condensing)
Optical Zoom
2.62
Protection
Vandal / weatherproof
Sensor Size (metric)
9.1 mm (1/2.8")
Total Pixels
2,000,000 pixels
Video Formats
H.264, H.265, MJPEG
Video Input
Color
Alarm Input Quantity
1
Alarm Output Quantity
1
Bundled With
AXIS License Plate Verifier
Country
Australia, Europe, United Kingdom, United States
Features
16:10 aspect ratio, 16:9 aspect ratio, 180° image rotation, 2 video streams, 2D digital noise reduction (DNR), 3D digital noise reduction (DNR), 4:3 aspect ratio, Access Control, Adaptive Bitrate (ABR), Auto AGC, Axis Edge Vault, Brightness control, Compression, Contrast control, Day/night threshold, Deep learning processing unit (DLPU), Defogging, Digital PTZ function, Dynamic text overlay, Exposure mode, Exposure zone, Forensic WDR, Full duplex audio, Half duplex audio, Image mirror, Image overlay, Infrared-cut filter, IR Corrected lens, License plate recognition (LPR), Lightfinder 2.0 technology, Low latency mode, Multi-Bitrate (MBR), NAS-Ready, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support, Polycarbonate housing, Polygon privacy mask, Remote focus, Remote zoom, Saturation control, Secure Boot, Sharpness control, Target aperture, Tone mapping, TPM 2.0 module, Variable Bit Rate (VBR), Vehicle Detection, Video streaming indicator, White balance, Zipstream technology
Packaged Quantity
1
Included Accessories
Cable gaskets, Connector guard, Drill hole template, Owner authentication key, Resitorx TR20 screw bit, Terminal block connector, Weathershield
Height
4.1 inch
Weight
28.22 ounce
Width
5.9 inch
Depth
5.9 inch
Color
NCS S 1002-B, White
Color Category
White
Compliant Standards
AS/NZS CISPR 32 Class A, BIS, CAN/CSA C22.2 No. 62368-1 Third Edition, CISPR 32 Class A, CISPR 35, Common Criteria EAL4+, CSA, cUL, EAC, EAL 6+, ECA, EN 50121-4, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 63000:2018, FCC Part 15 B Class A, ICES-3(A)/NMB-3(A), IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-6, IEC 60068-2-78, IEC 62236-4, IEC/EN 60529 IP66, IEC/EN 62262 IK10, IEEE 802.1ar, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, JEDEC, KC, KS C 9832 Class A, KS C 9835, NEMA TS-2 (2.2.7-2.2.9), NEMA250 Type 4X, NIST SP500-267, PVC-free, RCM, REACH 1907/2006/CE, RoHS 2011/65/EU, UKCA, UL, VCCI Class A, X.509
TAA Compliant
Yes
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
