Tech specs
Brand
Barco
Product Line
Barco Nio Color
Model
2MP LED MDNC-2221
Manufacturer
Barco
Interfaces
2 x USB 2.0 downstream, DisplayPort, DVI-D (dual link), USB 2.0 upstream
Bezel Type
Raised
Display Image Brightness
800 candela per square metre
Display Contrast Ratio
1400:1
Display Position Adjustments
Height, Pivot (rotation)
Display Screen Technology
TFT active matrix
Display Type
LED-backlit LCD monitor
Features
Anti-reflective, Backlight Output Stabilization (BLOS), DICOM calibrated, Integrated Front Sensor, Uniform Luminance Technology (ULT)
Form Factor
Desktop
Horizontal Viewing Angle
178
Input Signal
DVI-D, DisplayPort
Interface
DisplayPort, DVI
Medical Display Type
Color
Native Resolution
1600 x 1200
Pixel Pitch
0.27 millimetre
Response Time
20 millisecond
Screen Size
21.3 inch
Screen Size (metric)
54 centimetre
TFT Technology
IPS
Touchscreen
No
Vertical Viewing Angle
178
Monitor Aspect Ratio
4:3
Display Backlight Technology
LED backlight
Power Consumption (Typical)
36 watt
Software Type
Barco MediCal QAWeb
Built-in Devices
USB 2.0 hub
Built-in USB Hub
Yes
Flat Panel Mount Interface
100 x 100 mm
Medical
Yes
Packaged Quantity
1
Resolution
2MP
TV Tuner Presence
No
Cables
1 x DisplayPort cable, 1 x DVI cable, 1 x USB cable
Monitor Accessories Included
Protective cover
Comments
With stand
Dimensions Details
Without stand - width: 14.9 in - depth: 3.3 in - height: 19.3 in
Height
20.8 inch
Weight
27.78 lbs
Width
14.9 inch
Depth
9.3 inch
Color Category
Black
Compliant Standards
ANSI/AAMI ES60601-1:2005 + C1:2009 + A1:2012, CAN/CSA C22.2 No. 60601-1, CCC Class B, DEMKO, FCC Class B certified, FDA 510k, ICES Class B, IEC 60601-1:2005 + A1:2012, IEC 60601-1:2006, IEC 60950-1:2005 (ed.2)+A1:2009, KCC, RoHS, VCCI
ENERGY STAR Certified
No
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5 Year
