Tech specs
Brand
Ruckus
Product Line
Ruckus ICX
Model
7450-48P
Manufacturer
Ruckus Wireless
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.1AX, IEEE 802.1BR, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3ba, IEEE 802.3bt, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
Access Control List (ACL) support, Auto-uplink (auto MDI/MDI-X), BOOTP support, Class of Service (CoS), DHCP relay, DHCP server, DHCP snooping, DiffServ Code Point (DSCP) support, DiffServ support, Digital Optical Monitoring (DOM) support, DoS attack prevention, Dynamic ARP Inspection (DAI), Energy Efficient Ethernet, Flow control, Full duplex mode, Generic VLAN Registration Protocol (GVRP), High Availability, Hot swappable fan, IGMP proxy, IGMP snooping, IPv4 support, IPv6 support, LACP support, Link Fault Signaling (LFS), MAC address filtering, Management Information Base (MIB), Metro Ring Protocol (MRP) support, MLD snooping, Multiple Spanning Tree Protocol (MSTP) support, NTP time synchronization, OpenFlow support, Per-VLAN Rapid Spanning Tree (PVRST), Per-VLAN Spanning Tree (PVST), Per-VLAN Spanning Tree Plus (PVST+), Port based access control, Port mirroring, Port Security, Power over HDBaseT (PoH), Quality of Service (QoS), Rapid Spanning Tree Protocol (RSTP) support, Remote Fault Notification (RFN), sFlow, Spanning Tree Protocol (STP) support, STP Root Guard, Strict Priority (SP), Syslog support, Tagged VLAN, Trunking, Type of Service (ToS), Uni-Directional Link Detection (UDLD), Virtual Switch Redundancy Protocol (VSRP) support, VLAN Stacking, VLAN support, Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
32768 entries
Manageable
Yes
Max Units In A Stack
12
Ports
48
Power Over Ethernet (PoE)
PoH
Product Type
Switch
Remote Management
CLI, HTTP, HTTPS, RMON, SNMP 1, SNMP 2c, SNMP 3, Telnet, TFTP
Routing Protocol
ECMP, IGMP, IGMPv2, IGMPv3, MLD, MLDv2, MSDP, Static IPv4 routing, Static IPv6 routing
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Expansion Slots
3 (total) / 0 (free) x expansion slot
QSFP Slots
10 Gigabit SFP+
Interface Provided
1 x 1000Base-T RJ-45 management, 1 x mini-USB management, 1 x USB Type A, 2 x 40Gbit LAN QSFP+ uplink/stacking, 4 x 10Gbit LAN SFP+ uplink, 40 x 1000Base-T RJ-45 PoE+ - 30 W, 8 x 1000Base-T RJ-45 PoH - 90 W
Port Quantity
40
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
10/100/1000 (PoH)
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
106 watt
Power Provided
1000 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
Encryption
AES, ECDSA, IKEv2
Humidity Range Storage
5 - 95% (non-condensing)
Max Operating Temperature
122 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
23 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
444,360 Hours
Operating Humidity
10 - 90% (non-condensing)
Operating System Required
HP-UX, IBM AIX, Microsoft Windows, SunSoft Solaris
Airflow Direction
Front to back airflow
Authentication Method
Extensible Authentication Protocol (EAP), RADIUS, Secure Shell v.2 (SSH2), TACACS, TACACS+
Capacity
Hardware multicast groups: 8192, IPSec tunnels: 20, IPv4 routes: 15168, IPv6 routes: 5120, QoS hardware queues per port: 8, Spanning Tree Protocol instances: 254, Virtual interfaces (VLANs): 4096
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding performance: 250 Mpps, Stacking bandwidth: 160 Gbps, Switching capacity: 336 Gbps, VPN throughput (IPSec): 10 Gbps
Ports (2nd) Quantity
8
Ports (3rd) Quantity
4
Ports (4th) Quantity
2
Ports (4th) Type
40 Gigabit QSFP+
Height
1.7 inch
Height (Rack Units)
1
Weight
15.87 lbs
Width
17.3 inch
Depth
15.5 inch
Color Category
Black
Compliant Standards
CAN/CSA C22.2 No. 60950-1-07, CISPR 22 Class A, EN 60825-1, EN 60950-1:2006, EN 61000-3-2, EN 61000-3-3, EN 61000-4-11, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-6-1, EN 61000-6-3, EN55022 Class A, EN55024, FCC Part 15 A, HMAC, ICES-003, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IEC 60950-1, RoHS 6/6, UL 60950-1, VCCI Class A, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - lifetime
Limited Warranty
Limited Lifetime
