Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9115AXI
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
1 GB
RAM Installed
2 GB
Compliant Standards
IEEE 802.11ac Wave 2, IEEE 802.11ax, IEEE 802.11d, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3bz, Wi-Fi CERTIFIED 6
Connectivity Technology
Wireless
Data Link Protocols
Bluetooth 5.0, IEEE 802.11a, IEEE 802.11ac Wave 2, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
4x4 MU-MIMO technology, 8x8 MU-MIMO technology, Access Control List (ACL) support, Beamforming technology, Cisco Trust Anchor module, Cisco VideoStream technology, Cyclic shift diversity (CSD), DFS support, Dynamic QoS, Guest access, Image signing, Maximum Ratio Combining (MRC), Packet aggregation A-MPDU, Packet aggregation A-MSDU, Pre-Shared Key (PSK), Quality of Service (QoS), Radio resource management (RRM), Secure boot, Target Wait Time (TWT)
Form Factor
External
Network Band
2.4 GHz, 5 GHz
Network Standard
IPSec, IPv6
Power Over Ethernet (PoE)
UPOE
Product Type
Wireless access point
Remote Management
NETCONF, RESTCONF
Status Indicators
Status
Wireless LAN
802.11a/b/g/n/ac/ax, Bluetooth 5.0
Interface Provided
1 x 1/2.5GBase-T - RJ-45, 1 x management - RJ-45, 1 x USB 2.0
Software Type
CAPWAP Software Image
Antenna Form Factor
Internal
Directivity
Omni-directional
Encryption
AES, EAP-FAST, EAP-SIM, FIPS, PEAP, TLS, TTLS, WPA, WPA2
Internet of Things (IoT) Compatible
Yes
Line Coding Format
OFDMA
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 90% (non-condensing)
Authentication Method
EAP-FAST, EAP-SIM, Extensible Authentication Protocol (EAP), MS-CHAP v.2
Country
India
IoT Communications Technology
Bluetooth Low Energy (LE)
Packaged Quantity
1
Ruggedized Design
Indoor
Included Accessories
Ceiling grid clip, Low profile bracket
Height
1.7 inch
Weight
31.74 ounce
Width
8 inch
Depth
8 inch
Compliant Standards
ARPANSA, AS/NZS 2772, AS/NZS 4268, AS/NZS 60950-1, AS/NZS CISPR 32 Class B, CAN/CSA-C22.2 No. 60950-1, CISPR 24, CISPR 32, CNS 13438, EMI Class B, EN 300 328, EN 301 489-1, EN 301 489-17, EN 301 893, EN 50385, EN 55032, EN 55035, EN 60601-1-1, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 62209-1, EN 62209-2, EN55024, FCC CFR47 Part 15 B, FCC CFR47 Part 15 C, ICES-003, IEC 60950-1, KN 489-1, KN 489-17, KN 61000-3-2, KN 61000-3-3, KN32, LP0002, QCVN, RSP-100, RSS-102, RSS-247, RSS-GEN, SRRC, TCVN 7189, UL 2043, UL 60950-1, USGv6, VCCI V-3
Service & Support Details
Limited warranty - lifetime
Integrated System
Limited lifetime warranty
