Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200
Edition
Network Advantage
Manufacturer
CISCO DS HARDWARE DIRECT
Flash Memory Installed
4 GB
RAM Installed
4 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
Blue Beacon LED, Built-in ASIC, Cisco StackWise Technology, Control plane protection (CoPP), DNA support, Embedded Event Manager (EEM), First Hop Security (FHS), Flexible NetFlow (FNF), Location ID Separation Protocol (LISP), MACsec support, Protocol Independent Multicast (PIM), PVLAN support, Security Group Tag (SGT) caching, Superior QoS, Virtual Extensible LAN (VXLAN), Virtual Routing and Forwarding (VRF)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
Ports
24
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
NETCONF, RESTCONF
Routing Protocol
EIGRP, HSRP, IS-IS, MSDP, OSPF, PIM-SSM, Policy-based routing (PBR), RIP-1, RIP-2, RIPng, VRRP
Smart
Yes
Stackable
Stackable
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
24 x 10/100/1000 Base-T RJ-45 PoE+ - 30 W
Port Quantity
24
Port Type
10/100/1000 (PoE+)
Frequency
50 - 60 hertz
Hot-Plug
Hot-plug
Power Supplies Supported
2
Redundant Power Supply
Optional
Required Voltage
AC 100-240 volt
Software Type
Cisco Network Advantage
Built-in Devices
RFID tag
Encryption
128-bit AES
Humidity Range Storage
5 - 90% (non-condensing)
Max Storage Temperature
158 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
MTBF
422,310 Hours
Operating Humidity
5 - 90% (non-condensing)
Capacity
ACL scale entries: 1600, IPv4 routing table entries: 4000, IPv6 routing table entries: 2000, Packet buffer size: 6 MB, Switched virtual interfaces (SVIs): 1000, Virtual networks: 4, VLAN IDs: 4096
Device Type
Internal power supply
Packaged Quantity
1
Performance
Forwarding rate: 190.4 Mpps, Stacking bandwidth: 160 Gbps, Switching bandwidth: 128 Gbps
Height
13.8 inch
Weight
12.13 lbs
Width
1.7 inch
Depth
17.5 inch
Color Category
Gray
Compliant Standards
AS/NZS 3548 Class A, AS/NZS 60950-1, BSMI Class A, CAN/CSA-C22.2 No. 60950-1, CCC, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CISPR 35, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN55024, ICES-003 Class A, IEC 60950-1, KN32, KN35, Plug and Play, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day
Limited Warranty
Limited Lifetime
