Tech specs
Brand
Cisco
Product Line
Cisco Catalyst
Model
9200L
Edition
Network Essentials
Manufacturer
Cisco Systems
Flash Memory Installed
4 GB
RAM Installed
2 GB
Advanced Switching
Layer 3
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3bz, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
6MB packet buffer, Blue Beacon LED, Class of Service (CoS), Committed Information Rate (CIR), Control plane protection (CoPP), DiffServ Code Point (DSCP) support, EIGRP Stub Routing, Embedded Event Manager (EEM), Energy-Efficient Ethernet (EEE), First Hop Security (FHS), Flexible NetFlow (FNF), MACsec support, Protocol Independent Multicast (PIM), PVLAN support, Rapid Per-VLAN Spanning Tree Plus (PVRST+), Remote Switch Port Analyzer (RSPAN), Shaped Round Robin (SRR), Source-Specific Multicast (SSM), Superior QoS, Switched Port Analyzer (SPAN)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9198 bytes
Manageable
Yes
Ports
48
Power Over Ethernet (PoE)
PoE+
Product Type
Switch
Remote Management
NETCONF, RESTCONF, RMON 1, RMON 2, SNMP 1, SNMP 2c, SNMP 3
Routing Protocol
MSTP, OSPF, Policy-based routing (PBR), RIP, VRRP
Subcategory
Network hubs and switches
Switching Type
Gigabit Ethernet
Interface Provided
4 x 10GBase-X SFP+, 48 x 1000Base-T RJ-45 PoE+
Port Quantity
48
Port Type
10/100/1000 (PoE+)
Ports Type (2nd)
10 Gigabit SFP+
Power Supplies Supported
2
Required Voltage
AC 100-240 volt
Built-in Devices
RFID tag
MTBF
346,270 Hours
Capacity
ACL scale entries: 1500, FNF entries: 16000, IPv4 routes: 11000, IPv4 routing table entries: 3000, IPv6 routing table entries: 1500, MAC addresses: 16000, Multicast scale: 1000, Queues per port (egress): 8, Switched virtual interfaces (SVIs): 512, Virtual networks: 1
Device Type
Internal power supply (not installed)
Packaged Quantity
1
Performance
Forwarding rate: 261.9 Mpps, Stacking bandwidth: 80 Gbps, Switching capacity: 176 Gbps
Ports (2nd) Quantity
4
Height
11.3 inch
Weight
12.13 lbs
Width
17.5 inch
Depth
1.7 inch
Color Category
Gray
Compliant Standards
AES-128, AS/NZS 60950-1, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CISPR 32 Class A, CNS 13438, EN 300 386, EN 55022 Class A, EN 55032 Class A, EN 60950-1, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR47 Part 15, ICES-003 Class A, IEC 60950-1, KN32, KN35, Plug and Play, RoHS 5/6, TCVN 7189 Class A, TCVN 7317, UL 60950-1, V-3 Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - advance parts replacement - lifetime - response time: next business day
Limited Warranty
Limited Lifetime
