Tech specs
Depth
8 in
Height
2.3 in
Weight
6.61 lbs
Width
11.3 in
Humidity Range Operating
5 - 95% (non-condensing)
Max Operating Temperature
158 °F
Min Operating Temperature
-40 °F
Installed Size
64 MB
Brand
Cisco
Compatibility
PC
Manufacturer
Cisco Systems
Model
3700 Series
Packaged Quantity
1
Product Line
Cisco Industrial Wireless
Connector Type
8 pin M12
Qty
1, 4
Type
1000Base-T (PoE), 1000Base-T (PoE+), Antenna, Management
Authentication Method
EAP-FAST, Extensible Authentication Protocol (EAP), MS-CHAP v.2
Compliant Standards
AES, ARIB STD-T66, ARIB STD-T71, AS/NZS CISPR22:2004 Class A, CAN/CSA C22.2 No. 60950-1, CISPR 11 class A, CISPR 22 Class A, CISPR 24, CNS 13438(95) Class A, EMI, EN 300 328, EN 300386, EN 301 489-1, EN 301.489.17, EN 50121-3-2, EN 50121-4, EN 55022 Class A, EN 60529, EN 60950-1, EN 61000-4-18, EN 61000-4-2, EN 61000-4-29, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-9, EN 61000-6-1, EN 61000-6-2, EN 61000-6-4, EN 61326, EN 61373, EN50155, EN55024, FCC CFR47 Part 15, ICES-003, ICES-003 Class A, IEC 60068-2-1, IEC 60068-2-14, IEC 60068-2-2, IEC 60068-2-27, IEC 60068-2-30, IEC 60068-2-32, IEC 60068-2-6, IEC 60950-1, IP67, KN22, KN24, OET 65 C, RSS-102, RSS-210, TLS, UL 50E, UL 60950-1, VCCI, VCCI Class A
Encryption Algorithm
AES, PEAP, TKIP, TLS, TTLS, WPA, WPA2
Compliant Standards
IEEE 802.11a, IEEE 802.11ac (draft 5.0), IEEE 802.11b, IEEE 802.11d, IEEE 802.11g, IEEE 802.11h, IEEE 802.11i, IEEE 802.11n, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at, Wi-Fi CERTIFIED
Connectivity Technology
Wireless
Data Link Protocol
IEEE 802.11a, IEEE 802.11ac (draft 5.0), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Data Transfer Rate
1.3 Gbps
Features
4T4R MIMO technology, 802.1x authentication, Auto-sensing per device, Beamforming technology, CleanAir technology, ClientLink 3.0 technology, Cyclic shift diversity (CSD), DFS support, Maximum Ratio Combining (MRC), Power Sourcing Equipment (PSE), Wall mountable, Wi-Fi Multimedia (WMM) support
Form Factor
External
Power Over Ethernet (PoE)
PoE+
Status Indicators
Status
Type
Wireless access point
Wi-Fi Bands
2.4 GHz, 5 GHz
Wireless Protocol
802.11a/b/g/n/ac (draft 5.0)
Installed Size
512 MB
Support Details Full Contract Period
5 years
Support Details Type
Limited warranty
Type
5 years warranty
