Tech specs
Brand
Cisco
Product Line
Cisco UCS
Model
6454 Fabric Interconnect
Manufacturer
CISCO DS HARDWARE DIRECT
RAM Installed
64 GB
Compliant Standards
IEEE 802.1p, IEEE 802.1Q, IEEE 802.1Qaz, IEEE 802.1Qbb, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3bg, IEEE 802.3bm, IEEE 802.3by, IEEE 802.3x
Features
Breakout capability, Class of Service (CoS), Data Center Bridging Exchange (DCBX) support, Enhanced transmission selection, Fabric Extender Transceiver (FET), FCoE support, LACP support, Link Aggregation Control Protocol (LACP), Lossless fabric, Priority-based flow control, Priority-Based Flow Control (PFC), Quality of Service (QoS), Rapid Per-VLAN Spanning Tree Plus (PVRST+), Rapid PVST+ (RPVST+), VLAN encapsulation, Weighted Round Robin (WRR)
Form Factor (Hubs & Switches)
Rack-mountable
Jumbo Frame Support
9216 bytes
MAC Address Table Size
32000 entries
Manageable
Yes
Ports
54
Product Type
Switch
Remote Management
RMON
Routing Protocol
IGMP, IGMPv2, IGMPv3
Status Indicators
Error, Fan failure, Fault, Link/activity, Power
Subcategory
Network hubs and switches
Switching Type
100 Gigabit Ethernet
QSFP Slots
40/100 Gigabit QSFP28 (uplink)
Interface Provided
1 x 10/100/1000 Base-T RJ-45 management, 1 x USB, 36 x 10/25Gbit LAN SFP28 FCOE, 4 x 1/10/25Gbit LAN SFP28 FCOE, 6 x 100Gbit/40Gbit LAN QSFP28 FCOE / uplink, 8 x 10/25Gbit LAN or 8/16/32Gb Fibre Channel SFP28 FCOE / unified port
Port Quantity
36
Port Type
10/25 Gigabit SFP28
Ports Type (2nd)
1/10/25 Gigabit SFP28
Features
Port side exhaust
Hot-Plug
Hot-plug
Power Supplies Supported
2
Redundant Power Supply
Optional
Redundant Power Supply Supported
1+1 (with optional power supply)
Software Type
Cisco Intersight, Cisco UCS Manager 4.2
Built-in Devices
4 x fans
Max Operating Temperature
104 degree Fahrenheit
Max Storage Temperature
158 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Min Storage Temperature
-40 degree Fahrenheit
Operating Humidity
5 - 95% RH (non-condensing)
Airflow Direction
Front to back airflow
Capacity
Queues per port: 16, VLANs supported: 4000
Device Type
Internal power supply (not installed)
Packaged Quantity
1
Performance
Bandwidth: 200 Gbps, Layer 2 hardware forwarding: 1.2 billion bpps, Layer 2 hardware forwarding: 3.82 Tbps, Switching capacity: 3.82 Tbps
Ports (2nd) Quantity
4
Ports (3rd) Quantity
6
Ports (4th) Quantity
8
Ports (4th) Type
10/25 Gigabit Ethernet or 8/16/32 Gigabit Fibre Channel
Cables
8 x 25GBase-CU SFP28 Cable (3 m) - 10 ft
Included Accessories
Chassis accessory kit
Height
1.7 inch
Height (Rack Units)
1
Width
17.3 inch
Depth
22.5 inch
Color Category
Black
Compliant Standards
AS/NZS 60950-1, AS/NZS CISPR22 Class A, CAN/CSA-C22.2 No. 60950-1, CISPR 22 Class A, CISPR 24, CNS 13438 Class A, Directive 2004/108/EC, Directive 2006/95/EC, EN 300 386, EN 55022 Class A, EN 60950-1 Second Edition, EN 61000-3-2, EN 61000-3-3, EN55024, FCC CFR47 Part 15 A, GB 4943, ICES-003 Class A, IEC 60950-1 Second Edition, KN 61000-4, KN22 Class A, RoHS, UL 60950-1 Second Edition, VCCI Class A
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - replacement - 3 years - response time: next business day
Limited Warranty
3 Year
