Tech specs
Brand
Cisco
Product Line
Cisco Webex
Model
Desk Mini
Manufacturer
CISCO DS HARDWARE DIRECT
Compliant Standards
G.711, G.722, G.729
Connectivity Technology
Wired, Wireless
Data Link Protocols
Bluetooth, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Network Standard
HTTP
Data Compression Protocol
G.711, G.722, G.722.1, G.729
Digital Signaling Protocol
H.323, SIP
Interface Provided
1 x network - Ethernet 1000Base-T - RJ-45, 1 x USB 2.0 - 4 pin USB Type A, 1 x USB 2.0 - 5 pin Micro-USB Type B, 1 x USB-C - DisplayPort input - 24 pin USB-C
Aspect Ratio
16:9
Display Image Brightness
250 candela per square metre
Display Contrast Ratio
700:1
Display Screen Technology
IPS
Features
85° viewing angle
Native Resolution
1920 x 1080
Screen Size
15.6 inch
Screen Size (metric)
39.6 centimetre
Touchscreen
No
Audio Input Type
3-microphone array
Form Factor
Integrated
Frequency Response (Output)
65 - 20000 hertz
Output Type
Speaker(s)
Color Support
Color
Digital Video Capture Resolution
1080p
Form Factor
Integrated
Video Input Type
Digital video camera
Video Modes
1080/30p, 1080/60p
Required Voltage
AC 100-240 volt
Conferencing System Type
Video conferencing device
Input Device Type
15.6" touchscreen
Max Operating Temperature
95 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 90% RH
Voice Codec
AAC-LD, G.711, G.722, G.722.1, G.729, Opus
Features
1/3.2 CMOS image sensor type, 50° field of view (vertical), 64° field of view (horizontal), 8 megapixels image sensor, Auto white balance, Brightness control, F 2.0 lens aperture, Tilt Adjustment
Input Device Features
Acoustic Echo Cancellation, Automatic Gain Control (AGC), Multi-touch, Volume control
Packaged Quantity
1
Security
H.323
Video Codecs
H.263, H.264 AVC
VoIP Protocols
H.323, SIP
Cables
1 x USB-C cable
Height
16.3 inch
Weight
8.6 lbs
Width
14.6 inch
Depth
5.3 inch
Color
First light gray
Color Category
Gray
Compliant Standards
Directive 2002/96/EU, Directive 2011/65/EU, Directive 2014/30/EU, Directive 2014/35/EU, Directive 2014/53/EU, FCC, FCC CFR47 Part 15 B Class B, FCC CFR47 Part 15 C, FCC CFR47 Part 15 E, NRTL
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 90 days
Limited Warranty
90 Day
