Tech specs
Brand
Cisco
Product Line
Cisco Webex
Model
Room Kit Plus PTZ
Manufacturer
Cisco Systems
Compliant Standards
IEEE 802.1p, IEEE 802.1Q, IEEE 802.1x
Connectivity Technology
Wired, Wireless
Data Link Protocols
Bluetooth 4.0, Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Features
4K resolution support, 802.1x authentication, Administrator's password, Audio Return Channel (ARC), Automatic gain control (AGC), DiffServ support, Quality of Service (QoS), Security lock slot (cable lock sold separately), SSH support, URI Dialing, Wall mountable
IP Address Assignment
DHCP
Network Protocols
DNS, HTTP, HTTPS, NTP
Network Standard
DHCP, DNS, NTP
Data Compression Protocol
H.264
Digital Signaling Protocol
BFCP, H.323, H.460.18, H.460.19, SIP
Features
DTMF decoding
Interface Provided
1 x audio - output - mini-phone stereo 3.5 mm, 1 x display / video - HDMI input - 19 pin HDMI Type A, 1 x USB 2.0, 2 x display / video - HDMI input - 19 pin HDMI Type A, 2 x display / video - HDMI output - 19 pin HDMI Type A, 3 x audio - input - mini-phone 3.5 mm, 3 x network - RJ-45
Digital Video Standard
High-Definition Multimedia Interface (HDMI)
Supported Display Graphics
UHD (3840 x 2160)
Touchscreen
No
Camera Mechanical Design
Pan / tilt / zoom
Color Support
Color
Digital Video Capture Resolution
1920 x 1080, 3840 x 2160
Digital Zoom
12
Form Factor
External
Interface Type
HDMI
Video Input Type
Digital video camera
Frequency
50/60 hertz
Power Device Type
Power supply
Required Voltage
AC 100-240 volt
Conferencing System Type
Video conferencing kit
Power Device Form Factor
External
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
20 - 80% RH
Optical Zoom
20
Voice Codec
AAC-LD, G.711, G.722, G.722.1, G.729, Opus
Features
-170° / +170° pan, -20° / +20° tilt, 70° field of view (horizontal), Auto white balance, Autofocus, Automatic brightness adjustment, F 2.0-3.8 lens aperture, Manual brightness adjustment, Manual white balance
Packaged Quantity
1
Quality of Service
Differentiated Services (DiffServ), IEEE 802.1p, IEEE 802.1Q (VLAN)
Security
H.235 v3, IEEE 802.1X
Video Codecs
H.264
VoIP Protocols
H.323
Dimensions Details
Camera - Width 6.2 in Depth 7.9 in Height 7 in Weight 3.7 lbs, Main system - Width 14.1 in Depth 5.6 in Height 1.7 in Weight 3.9 lbs
Color Category
White
Compliant Standards
Directive 2002/96/EU, Directive 2011/65/EU, Directive 2014/30/EU, EMC, EN 55032 Class A, EN 55035, EN 62368-1, FCC CFR47 Part 15 B, NRTL, RoHS, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 90 days, Limited warranty - advance parts replacement - 10 days
Limited Warranty
90 Day
