Tech specs
Brand
Cooler Master
Product Line
Cooler Master G Series
Model
G500 GOLD
Manufacturer
Cooler Master
Cooling System
120 mm fan
Emergency Power Off
Hydrodynamic bearing cooling fan, Non-modular, Overcurrent protection, Overheat protection, Overpower protection, Overvoltage protection, Short-circuit protection, Undervoltage protection
Frequency
47 - 63 hertz
Output Current
+12V - 41.6 A, +3.3V - 20 A, +5V - 20 A, +5VSB - 3 A, -12V - 0.3 A
Power Factor Correction
Active Power Factor Correction (PFC)
Power Output Connectors Details
1 x power 24 pin ATX, 1 x power 8 pin EPS12V, 1 x power 8 pin EPS12V with detachable 4 pin ATX12V section, 2 x 8 pin PCI Express power with detachable 2 pin section, 3 x 4 pin internal power, 6 x 15 pin Serial ATA power
Power Provided
500 watt
Power Supply Compatibility
PC/Server
Provided Voltage
+3.3, +5, ±12 volt
PSU Form Factor
ATX
Required Voltage
AC 100 - 240 volt
Specification Compliance
ATX12V 2.52/ EPS12V
80 PLUS Certification
80 PLUS Gold
Efficiency
90%
Form Factor (Power Device)
Internal
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
100,000 Hours
Country
United States
Packaged Quantity
1
Product Type
Power Supply
Subcategory
Power supplies
Height
3.4 inch
Weight
3.48 lbs
Width
5.9 inch
Depth
5.5 inch
Color Category
Black
Compliant Standards
BIS, BSMI, CB, CCC, cTUVus, EAC, ErP Lot 3 2014 Ready, FCC, KC, KCC, RoHS 2.0, TUV
ENERGY STAR Certified
No
Service & Support Details
Limited warranty - 5 years
Limited Warranty
5-year warranty
