Tech specs
Brand
CyberPower
Product Line
CyberPower PFC Sinewave Series
Model
OR1000PFCRT2U
Manufacturer
Cyber Power
Remote Management Interface
Serial, USB
Input Connectors
1
Interface Provided
1 x EPO (emergency power off), 1 x management (USB), 1 x serial - 9 pin D-Sub (DB-9)
Batteries Quantity
2
Battery Capacity
9 Ah
Battery Recharge Time
10 Hours
Battery Technology
Lead acid
Battery Voltage
12 volt
Dataline Surge Protection
Network/phone line - RJ-45/RJ-11 - 1 input line / 1 output line
Emergency Power Off
Audible alarm, Automatic Voltage Regulation (AVR), GreenPower UPS Technology, LCD display, LED indicators, Noise filtering, Overload protection, Right-angle outlets
Frequency
60 hertz
Frequency Provided
60 hertz
Frequency Provided Margin
± 1%
Frequency Required Margin
± 3Hz
Input Connector Type
Power NEMA 5-15P
Input Voltage Range
AC 88 - 139 V
Input Voltage Range (Adjustable)
AC 86 - 142 V
Lead Acid Battery Features
Sealed
Load Type
At full load
Max Run Time
17.9 min at half load, 6.6 min at full load
Output Connector Quantity
8
Output Connector Type
Power NEMA 5-15
Power Capacity
1000 volt ampere per kilogram
Power Factor (PF)
0.7
Power Output Connectors Details
8 x power NEMA 5-15
Power Provided
700 watt
Provided Voltage
AC 120 volt
Required Voltage
AC 120 volt
Surge Suppression
Yes
UPS Technology
Line interactive
Voltage Provided Margin
± 5%
Waveform Type
Sine Wave
Battery Run Time (Up To)
6.6 minute (time unit)
Software Type
PowerPanel Business Edition
Form Factor (Power Device)
Rack-mountable / external
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
0 - 95% (non-condensing)
Protection Type
Circuit breaker
Sound Emission
48.5 dBA
Features
Hot-swappable battery
Packaged Quantity
1
Product Type
UPS
Subcategory
UPS
Cables
Power cable 10 ft, USB cable
Height
3.5 inch
Height (Rack Units)
2
Weight
37.48 lbs
Width
17 inch
Depth
15.3 inch
Color Category
Black
Compliant Standards
cUL, FCC Class A certified, RoHS, UL
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Equipment Protection Value
300000 US Dollars
Service & Support Details
Limited warranty - 3 years
Limited Warranty
3 Year
Surge Energy Rating
1470 joules
