Tech specs
Brand
D-Link
Product Line
D-Link DES
Model
1210
Manufacturer
D-Link
RAM Installed
512 kilobyte
Compliant Standards
IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Features
Access Control List (ACL) support, ARP support, Auto-negotiation, Auto-uplink (auto MDI/MDI-X), BOOTP support, Broadcast Storm Control, DHCP snooping, DHCP support, Flow control, Full duplex mode, Half duplex mode, IGMP snooping, IP address filtering, Layer 2 switching, MAC address filtering, Multicast Storm Control, Port mirroring, Power over Ethernet (PoE), Quality of Service (QoS), Safeguard Engine, SNTP support, Static IP mode, Store and forward, Syslog support, Unicast Storm Control, VLAN support, Weighted Round Robin (WRR) queuing
Form Factor (Hubs & Switches)
Desktop
MAC Address Table Size
8K entries
Manageable
Yes
Ports
24
Power Over Ethernet (PoE)
PoE
Product Type
Switch
Remote Management
HTTP, HTTPS, SNMP 1, SNMP 2, SNMP 3, Telnet, TFTP
Status Indicators
Link OK, Link/activity, Port transmission speed, Power
Subcategory
Network hubs and switches
Switching Type
Fast Ethernet
QSFP Slots
10/100/1000
Interface Provided
2 x SFP (mini-GBIC), 24 x 100Base-TX RJ-45, 4 x 1000Base-T RJ-45
Port Quantity
24
Port Type
10/100
Ports Type (2nd)
Combo Gigabit SFP
Frequency
50/60 hertz
Power Consumption Operational
254 watt
Software Type
Drivers & Utilities
Encryption
SSL, SSL 2.0, SSL 3.0
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
MTBF
197,343 Hours
Operating Humidity
10 - 95%
Device Type
Internal power supply
Packaged Quantity
1
Ports (2nd) Quantity
2
Ports (3rd) Quantity
2
Rack Mounting Kit
Included
Height
1.7 inch
Height (Rack Units)
1
Weight
5.73 lbs
Width
17.3 inch
Depth
8.3 inch
Compliant Standards
C-Tick, cUL, FCC Class A certified, VCCI Class A ITE
