Tech specs
Brand
Dell
Product Line
Dell UltraSharp
Model
U2520D
Series
UltraSharp
Manufacturer
Smart Selection Video
Interfaces
2 x USB 3.0 downstream, Audio line-out, DisplayPort 1.4, DisplayPort output (MST), HDMI, USB 3.0 downstream with Battery Charging 1.2, USB-C (power up to 90W), USB-C downstream
Bundled Services
3 years Advanced Exchange Service
Bezel Type
Flat front
Display Image Brightness
350 candela per square metre
Color Support
16.8 million colors
Display Contrast Ratio
1000:1
Display Position Adjustments
Height, Pivot (rotation), Swivel, Tilt
Display Screen Coating
3H Hard Coating, Anti-glare
Display Screen Technology
TFT active matrix
Display Type
LED-backlit LCD monitor
Features
99% sRGB color gamut, Delta E<2 calibration, LED edgelight system
Form Factor
Desktop
Height Adjustment
5.1 inch
Horizontal Viewing Angle
178
Input Signal
HDMI, DisplayPort, USB-C
Interface
DisplayPort, HDMI, USB-C
Native Resolution
2560 x 1440
Pixel Density (ppi)
117.5
Pixel Pitch
0.216 millimetre
Response Time
5 millisecond
Rotation Angle
180
Screen Size
25 inch
Screen Size (metric)
63.44 centimetre
Swivel Angle
90
TFT Technology
IPS
Tilt Angle
-5/+21
Typical Response Time
5 ms (gray-to-gray fast), 8 ms (gray-to-gray normal)
Vertical Viewing Angle
178
Video Format
QHD
Video Format (Non-standard)
QHD
V-Sync Rate at Max Res.
60 hertz
Monitor Aspect Ratio
16:9
Display Backlight Technology
WLED backlight
Energy Class
Class F
Frequency
50/60 hertz
Power Consumption (On mode)
22 watt
Power Consumption (Typical)
24 watt
Power Consumption HDR (On mode)
16.1 kWh/1000h
Sleep-Mode Power Consumption
0.3 watt
Software Type
Dell Display Manager
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
10 - 80% (non-condensing)
Features
Anti-theft protection, Security Lock slot (cable lock sold separately), VESA interface support
Flat Panel Mount Interface
100 x 100 mm
Packaged Quantity
1
TV Tuner Presence
No
USB Power Delivery
90 watt
Cables
1 x DisplayPort cable, 1 x power cable, 1 x USB-C cable, 1 x USB-C to USB-A cable
Comments
With stand
Dimensions Details
With stand - width: 22.4 in - depth: 7.3 in - height: 15.1 in - weight: 14.1 lbs, Without stand - width: 22.4 in - depth: 2 in - height: 13.1 in - weight: 9.3 lbs
Height
15.1 inch
Weight
14.11 lbs
Width
22.4 inch
Depth
7.3 inch
Color Category
Black
Compliant Standards
BFR-free, Mercury-free, PVC-free, RoHS
ENERGY STAR Certified
Yes
Compatibility Specs
Dell Latitude 5320, 5520 ¦ Dell Precision 7560 ¦ Dell XPS 13 9310, 15 9510
Energy Efficiency Class (HDR) (from 1st March, 2021)
Class E
Standby Power Consumption
0.3 watt
