Tech specs
Brand
EVGA
Product Line
EVGA
Model
SuperNOVA 1000 GQ
Manufacturer
EVGA
Cooling System
135 mm fan
Emergency Power Off
Eco-Mode, Fluid dynamic bearing cooling fan, Fully modular, Overcurrent protection, Overpower protection, Overvoltage protection, Power-On Self-Test (POST), Short-circuit protection, Single 12V rail, Undervoltage protection
Frequency
50 - 60 hertz
Output Current
+12V - 83.3 A, +3.3V - 25 A, +5V - 25 A, +5VSB - 3 A, -12V - 0.5 A
Power Output Connectors Details
1 x 4 pin mini-power connector, 1 x power 24 pin ATX, 12 x 15 pin Serial ATA power, 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section, 4 x 4 pin internal power, 8 x 8 pin PCI Express power with detachable 2 pin section
Power Provided
1000 watt
Power Supply Compatibility
PC/Server
Provided Voltage
+3.3, +5, ±12 volt
Required Voltage
AC 100-240 volt
80 PLUS Certification
80 PLUS Gold
Form Factor (Power Device)
Internal
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Modular
Yes
MTBF
100,000 hour(s)
Packaged Quantity
1
Product Type
Power Supply
Subcategory
Power supplies
Height
3.4 inch
Weight
8.99 lbs
Width
5.9 inch
Depth
5.9 inch
Color Category
Black
Compliant Standards
CB, cTUVus, ErP Lot 3 2014 Ready, FCC, RCM, RoHS, TUV, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 10 years
Limited Warranty
10 Year
