Tech specs
Brand
EVGA
Product Line
EVGA
Model
SuperNOVA 750 GT
Manufacturer
EVGA
Cooling System
135 mm fan
Emergency Power Off
Eco-Mode, Fluid dynamic bearing cooling fan, Fully modular, Overcurrent protection, Overheat protection, Overpower protection, Overvoltage protection, Power-On Self-Test (POST), Short-circuit protection, Undervoltage protection
Frequency
50/60 hertz
Output Current
+12V - 62.5 A, +3.3V - 20 A, +5V - 20 A, +5VSB - 3 A, -12V - 0.3 A
Power Output Connectors Details
1 x 4 pin mini-power connector, 1 x power 24 pin ATX, 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section, 3 x 4 pin internal power, 4 x 8 pin PCI Express power with detachable 2 pin section, 6 x 15 pin Serial ATA power
Power Provided
750 watt
Power Supply Compatibility
PC/Server
Provided Voltage
+3.3, +5, ±12 volt
PSU Form Factor
ATX
Required Voltage
AC 100-240 volt
Specification Compliance
ATX12V / EPS12V
80 PLUS Certification
80 PLUS Gold
Efficiency
90% (115VAC) / 92% (220-240VAC)
Form Factor (Power Device)
Internal
Max Operating Temperature
122 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Modular
Yes
MTBF
100,000 hour(s)
Packaged Quantity
1
Product Type
Power Supply
Subcategory
Power supplies
Height
3.3 inch
Weight
5 lbs
Width
5.9 inch
Depth
5.9 inch
Color Category
Black
Compliant Standards
CB, cTUVus, ErP Lot 3 2014 Ready, FCC, RCM, RoHS, TUV, WEEE
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
Service & Support Details
Limited warranty - 7 years
Limited Warranty
7 Year
