Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
3201F
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC CP9/NP7
Hard Drive Capacity
1 TB
Port Expansion Hard Drive Type
SSD
Installed Quantity
2
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, 100 Gigabit Ethernet, 200 Gigabit Ethernet, 25 Gigabit Ethernet, 40 Gigabit Ethernet, 400 Gigabit Ethernet, 50 Gigabit Ethernet, Gigabit Ethernet
Features
CAPWAP support, High Availability, SSL inspection, Trusted Platform Module (TPM), Virtual Extensible LAN (VXLAN), VPN support
Form Factor
Rack-mountable
Network Standard
DNS, HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP/IP
Product Type
Security appliance
Remote Management
HTTP, HTTPS
Status Indicators
Alarm, HA, Link/activity, Power, Status
Interface Provided
1 x console - RJ-45, 1 x USB 3.0, 10 x 10Gb Ethernet/25Gb Ethernet/50Gb Ethernet - SFP+/SFP28/SFP56, 2 x 10Gb Ethernet (management) - RJ-45, 2 x 10Gb Ethernet/25Gb Ethernet/50Gb Ethernet (High Availability) - SFP+/SFP28/SFP56, 4 x 10Gb Ethernet/25Gb Ethernet (ultra-low latency) - SFP+/SFP28, 4 x 40Gb Ethernet/100Gb Ethernet/200Gb Ethernet/400Gb Ethernet - QSFP+/QSFP28/QSFP56/QSFP-DD
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
527 watt
Power Supplies Installed
2
Power Supplies Supported
2
Redundant Power Supply
Yes
Required Voltage
AC 100-240 volt
80 PLUS Certification
80 PLUS
Operating System Edition
FortiOS
Encryption
256-bit AES, 256-bit SHA, SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 90% (non-condensing)
Airflow Direction
Front to back airflow
Capacity
Client to gateway IPSec VPN tunnels: 200000, Concurrent SSL VPN users: 30000, Concurrent TCP sessions: 70000000, Firewall policies: 200000, Gateway to gateway IPSec VPN Tunnels: 40000, Maximum virtual domains: 500, New TCP sessions per second: 800000, Number of FortiAP devices (tunnel): 2048, Number of FortiAP devices: 4096, Number of FortiSwitches: 300, Number of FortiToken devices: 20000, Number of registered FortiClients: 20000, SSL inspection concurrent sessions: 7400000, SSL inspection CPS: 30000, Virtual domains: 10
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Application control throughput: 109 Gbps, CAPWAP throughput: 65 Gbps, Firewall latency (64-byte UDP): 3.42 μs, Firewall throughput (1518-byte UDP): 387 Gbps, Firewall throughput (512-byte UDP): 385 Gbps, Firewall throughput (64-byte UDP): 178.5 Gbps, Firewall throughput: 267.75 Mpps, IPS throughput (enterprise traffic mix): 63 Gbps, IPv6 firewall throughput (1518-byte UDP): 387 Gbps, IPv6 firewall throughput (512-byte UDP): 385 Gbps, IPv6 firewall throughput (86-byte UDP): 178.5 Gbps, NGFW throughput (enterprise traffic mix): 47 Gbps, SSL inspection throughput: 29 Gbps, Threat protection throughput (enterprise traffic mix): 45 Gbps, VPN throughput (512-bit IPSec): 105 Gbps, VPN throughput (SSL): 11 Gbps
Included Accessories
2 x SR 10Gbps SFP+ transceivers
Height
3.5 inch
Height (Rack Units)
2
Weight
45.64 lbs
Width
17.4 inch
Depth
23.9 inch
Color Category
White
Compliant Standards
CB, cUL, FCC Part 15 A, RCM, UL, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
