Tech specs
Brand
Fortinet
Product Line
Fortinet FortiGate
Model
401F
Manufacturer
Fortinet
Processor Brand
Fortinet
Processor Type
FortiASIC CP9/NP7
Hard Drive Capacity
480 GB
Port Expansion Hard Drive Type
SSD
Installed Quantity
2
Connectivity Technology
Wired
Data Link Protocols
10 Gigabit Ethernet, Ethernet, Fast Ethernet, Gigabit Ethernet
Features
CAPWAP support, High Availability, IP tunnel acceleration, SD-WAN support, SSL inspection, Trusted Platform Module (TPM), VPN support, Zero Trust Network Access (ZTNA)
Form Factor
Rack-mountable
Network Standard
HTTP, HTTPs, IPSec, IPv4, IPv6, TCP/IP, UDP/IP
Product Type
Security appliance
Remote Management
HTTP, HTTPS
Status Indicators
Alarm, HA, Power, Status
Interface Provided
1 x 1000Base-T (HA) - RJ-45, 1 x 1000Base-T (management) - RJ-45, 1 x console - RJ-45, 1 x USB - Type A, 16 x 1000Base-T - RJ-45, 4 x 1000Base-X/10GBase-X - SFP+, 4 x 10GBase-X (ultra-low latency) - SFP+, 8 x 1000Base-X - SFP
Frequency
50/60 hertz
Hot-Plug
Hot-plug
Power Consumption Operational
161.1 watt
Power Supplies Supported
2
Redundant Power Supply
Yes
Required Voltage
AC 100-240 volt
80 PLUS Certification
80 PLUS
Operating System Edition
FortiOS
Encryption
256-bit AES, 256-bit SHA, SSL, TLS 1.3
Max Operating Temperature
104 degree Fahrenheit
Min Operating Temperature
32 degree Fahrenheit
Operating Humidity
5 - 90% (non-condensing)
Airflow Direction
Front and side to back
Capacity
Client to gateway IPSec VPN tunnels: 50000, Concurrent SSL VPN users: 5000, Concurrent TCP sessions: 7800000, Firewall policies: 10000, Gateway to gateway IPSec VPN Tunnels: 2000, Maximum virtual domains: 10, New TCP sessions per second: 500000, Number of FortiAP devices (tunnel): 256, Number of FortiAP devices: 512, Number of FortiSwitches: 72, Number of FortiToken devices: 5000, SSL inspection concurrent sessions: 800000, SSL inspection CPS: 6000, Virtual domains: 10
Device Type
Internal power supply
Packaged Quantity
1
Service Activation
No
Network Device
Application control throughput: 28 Gbps, CAPWAP throughput: 65 Gbps, Firewall latency (64-byte UDP): 4.19 µs, Firewall latency (64-byte UDP, ULL ports): 2.5 µs, Firewall throughput: 105 Mpps, IPS throughput (enterprise traffic mix): 12 Gbps, IPv4 firewall throughput (1518-byte UDP): 79.5 Gbps, IPv4 firewall throughput (512-byte UDP): 78.5 Gbps, IPv4 firewall throughput (64-byte UDP): 70 Gbps, IPv6 firewall throughput (1518-byte UDP): 79.5 Gbps, IPv6 firewall throughput (512-byte UDP): 78.5 Gbps, IPv6 firewall throughput (86-byte UDP): 70 Gbps, NGFW throughput (enterprise traffic mix): 10 Gbps, SSL inspection throughput: 8 Gbps, Threat protection throughput (enterprise traffic mix): 9 Gbps, VPN throughput (512-bit IPSec): 55 Gbps, VPN throughput (SSL): 3.6 Gbps
Included Accessories
2 x 1Gb Ethernet SX SFP transceiver
Height
1.7 inch
Height (Rack Units)
1
Weight
14.33 lbs
Width
17 inch
Depth
15 inch
Color Category
White
Compliant Standards
CB, cUL, FCC Part 15 A, ICSA Antivirus, ICSA Firewall certified, ICSA IPS, ICSA IPSec certified, ICSA SSL-VPN, RCM, UL, USGv6, VCCI
ENERGY STAR Certified
No
EPEAT Compliant
No
TCO Certified
No
